DLK-324

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

DOOR HANDLE

4. Remove door side grommet, and loosen screw that retains the

rear door outside handle bracket.

5. While pulling outside handle (1), remove outside handle

escutcheon (2).

6. While pulling outside handle (1), slide toward rear of vehicle to

remove outside handle.

7. Remove front gasket (1) and rear gasket (2).

: Front

8. Slide outside handle bracket toward rear of vehicle to remove.

: Front

JMKIA1467ZZ

JMKIA5342ZZ

AWKIA1997ZZ

JMKIA5889ZZ

JMKIA5890ZZ

DOOR HANDLE

DLK-325

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

9. Remove clip and disconnect the outside handle cable from the

outside handle bracket.

INSTALLATION

Installation in the reverse order of removal.

CAUTION:

• When installing do not reuse rear door outside handle bracket screw. Always replace screw with new

ones when removed.

• Check rear door lock cable is properly engaged to outside handle bracket.

• After installation, check rear door open/close, lock/unlock operation.

PIIB5815E

DLK-326

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

DOOR LOCK

DOOR LOCK

FRONT DOOR LOCK
FRONT DOOR LOCK : Exploded View

INFOID:0000000009756642

FRONT DOOR LOCK : Removal and Installation

INFOID:0000000009756643

CAUTION:

Before servicing, turn ignition switch OFF, disconnect both battery terminals and wait at least three

minutes.

REMOVAL

1. Remove the front door outside handle. Refer to

DLK-173, "FRONT DOOR HANDLE : Removal and Instal-

lation - Outside Handle"

.

2. Remove the rear glass run.
3. Disconnect the harness connector from the front door lock actuator.

1.

Outside handle bracket

2.

Front gasket

3.

Outside handle

4.

Door lock assembly

5.

Door striker

6.

Door key cylinder rod

7.

Inside handle assembly

8.

Outside handle escutcheon

9.

Rear gasket

ALKIA2939ZZ

DOOR LOCK

DLK-327

< REMOVAL AND INSTALLATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

4. Remove screws, and the door lock assembly.

INSTALLATION

Installation is in the reverse order of removal.

Tighten front door lock screws to specified torque.

CAUTION:

• Do not reuse front door lock assembly screws. Always replace screws with new ones when

removed.

• Check front door lock cables are properly engaged to inside handle and outside handle bracket.

• When installing door key cylinder rod on the LH front door, be sure to rotate door key cylinder rod

holder until a click is felt.

• After installation, check front door open/close, lock/unlock operation.

• Check front door lock assembly for poor lubrication. If necessary apply a suitable multi-purpose

grease.

REAR DOOR LOCK

PIIB5812E

Front door lock screws:

5.8 N·m (0.59 kg-m, 51 in-lb)
