Nissan Sentra. Manual - part 270

DLK-196

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

OUTSIDE KEY ANTENNA

OUTSIDE KEY ANTENNA

DRIVER SIDE
DRIVER SIDE : Removal and Installation

INFOID:0000000009756510

The driver side outside key antenna and driver side outside handle are serviced as an assembly. Refer to

DLK-173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle"

.

PASSENGER SIDE
PASSENGER SIDE : Removal and Installation

INFOID:0000000009756511

The passenger side outside key antenna and passenger side outside handle are serviced as an assembly.

Refer to

DLK-173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle"

.

Installation is in the reverse order of removal.

REAR BUMPER
REAR BUMPER : Removal and Installation

INFOID:0000000009756513

REMOVAL

1. Remove rear bumper fascia. Refer to

EXT-20, "Removal and Installation"

.

2. Disconnect the harness connector (B) from the rear bumper key

antenna (1).

3. Remove the nuts (A) that retain the rear bumper key antenna (1)

to the body.

INSTALLATION

Installation is in the reverse order of removal.

ALKIA2723ZZ

DOOR REQUEST SWITCH

DLK-197

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

DOOR REQUEST SWITCH

DRIVER SIDE
DRIVER SIDE : Removal and Installation

INFOID:0000000009756514

The driver side door request switch and driver side outside handle are serviced as an assembly. Refer to

DLK-

173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle"

.

PASSENGER SIDE
PASSENGER SIDE : Removal and Installation

INFOID:0000000009756515

The passenger side door request switch and passenger side outside handle are serviced as an assembly.

Refer to

DLK-173, "FRONT DOOR HANDLE : Removal and Installation - Outside Handle"

.

TRUNK LID FINISHER
TRUNK LID FINISHER : Removal and Installation

INFOID:0000000009756516

REMOVAL

1. Remove the license lamp finisher. Refer to

EXT-44, "Removal and Installation"

.

2. Release the pawls and remove the trunk lid request switch (1).

: Pawl

INSTALLATION

Installation is in the reverse order of removal.

ALKIA2722ZZ

DLK-198

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

INTELLIGENT KEY WARNING BUZZER

INTELLIGENT KEY WARNING BUZZER

Removal and Installation

INFOID:0000000009756517

REMOVAL

NOTE:

The Intelligent Key warning buzzer is located in the front passenger side area of the engine compartment,

near the washer tank.
1. Remove the washer tank inlet. Refer to

WW-51, "Exploded View"

.

2. Remove the nut (B) and the Intelligent Key warning buzzer (1).
3. Disconnect the harness connector (A) from the Intelligent Key

warning buzzer (1) and remove.

INSTALLATION

Installation is in the reverse order of removal.

ALKIA2933ZZ

REMOTE KEYLESS ENTRY RECEIVER

DLK-199

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

REMOTE KEYLESS ENTRY RECEIVER

Removal and Installation

INFOID:0000000009756518

REMOVAL

1. Remove glove box assembly. Refer to

IP-22, "Removal and Installation"

.

2. Disconnect the harness connector from the remote keyless entry receiver.
3. Remove the screw and remote keyless entry receiver.

INSTALLATION

Installation is in the reverse order or removal.
