DLK-156
< REMOVAL AND INSTALLATION >
[WITH INTELLIGENT KEY SYSTEM]
HOOD
6. Connect the hood lock release cable to the hood lock assembly.
7. Perform hood fitting adjustment. Refer to
DLK-150, "HOOD ASSEMBLY : Adjustment"
8. Perform the hood lock control inspection.
INSPECTION
NOTE:
If the hood lock release cable is bent or deformed, replace it.
1. Check that the secondary latch is properly engaged with the secondary striker and meets specification
provided (B) with hood's own weight.
2. While operating the hood lock release handle, carefully check that the front end of the hood assembly is
raised and meets the specification provided (A). Also check that the hood lock release handle returns to
the original position.
3. Check that the hood lock release handle operating force is 49 N (5.0 kg, 11 lb) or less.
4. Install so the static closing force of the hood assembly is 49 – 490 N (5.0 – 50 kg-f, 36 - 110.2 lb-f).
5. Check the hood lock assembly lubrication condition. If neces-
sary, apply a suitable multi-purpose grease as shown.
PIIB5802E
1.
Hood striker
2.
Primary latch
3.
Secondary striker
4.
Secondary latch
A.
21
± 1mm (0.8 ±0.04 in)
B.
6.8 mm (0.27 in)
PIIB5794E
ALKIA0028GB
