DLK-32
< SYSTEM DESCRIPTION >
[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
*: M/T models do not apply.
WARNING METHOD
The following table shows the alarm or warning methods with chime.
OFF position warning
For internal
When condition A, B or condition C is satisfied
• Condition A
- Ignition switch: ACC position
- Door switch (driver side): ON (Door is open)
• Condition B
- Turn ignition switch from ON to OFF while door is open
• Condition C
- Intelligent Key backside is contacted to push-button ignition switch while
brake pedal is depressed and ignition switch is LOCK or OFF (When the
Intelligent Key battery is discharged)
- Door switch (driver side): ON (Door is open)
For external*
OFF position warning (For internal) is in active mode, driver side door has
been closed.
NOTE:
OFF position (For external) active only when each of the sequence has oc-
curred as below: P position warning
→ ACC warning → OFF position warn-
ing (For internal)
→ OFF position warning (For internal)
P position warning
For internal
• Shift position: Other than P
• Engine is stopped (Ignition switch is turned from ON to OFF)
For external
• P position warning (For internal) operates
• Door switch: ON to OFF (Door is open to close)
• Intelligent Key cannot be detected inside the vehicle
ACC warning
• After P position warning operates, or when ignition switch is turned ON
immediately after P position warning operates
• Ignition switch: ACC
Take away warning
Door status changes
from open to close
• Ignition switch: Other than LOCK and OFF
• Door switch: ON to OFF (Door status changes from open to close)
• Registered Intelligent Key is not detected inside the vehicle
Door status is open
• Ignition switch: Other than LOCK and OFF
• Door switch: ON (Door is open)
• Registered Intelligent Key is not detected inside the vehicle during Key
ID verification for 5 seconds
Push button-ignition
switch operation
• Ignition switch: Other than LOCK position
• Push-button ignition switch is pressed
• Registered Intelligent Key is not detected inside the vehicle
Door lock operation warning
Door lock operation is requested while door lock operation condition of
door request switch is not satisfied
Engine start information
Ignition switch is ON po-
sition
• Ignition switch: ON position
• Shift position: P
• Engine is stopped
Ignition switch is other
than ON position
• Ignition switch: Other than ON
• Shift position: P
• Intelligent Key is in the passenger room after driver door is opened and
closed
Ignition switch is ON po-
sition to OFF position
• Ignition switch: ON position to OFF position
• Shift position: P position
NOTE:
Engine start information turns ON for several seconds and then turns OFF,
when ignition switch is turned to the ON position from the OFF position. En-
gine start information does not turn ON until opening and closing of driver
door is detected again.
Intelligent Key low battery warning
BCM detects that Intelligent Key is low battery, after ignition switch is turned
ON
Key ID warning
• Push-button ignition switch is pressed
• Registered Intelligent Key is not detected inside the vehicle
Warning/Information functions
Operation procedure
