AV-188 < DTC/CIRCUIT DIAGNOSIS > [DISPLAY AUDIO WITH BOSE] AMP ON SIGNAL CIRCUIT AMP ON SIGNAL CIRCUIT Diagnosis Procedure INFOID:0000000009758903 Regarding Wiring Diagram information, refer to . 1. CHECK CONTINUITY BETWEEN AUDIO UNIT AND BOSE SPEAKER AMP. 1. Turn ignition switch OFF. 2. Disconnect audio unit connector M94 and Bose speaker amp. connector B43. 3. Check continuity between audio unit connector M94 and Bose speaker amp. connector B43. 4. Check continuity between audio unit connector M94 and ground. Is the inspection result normal? YES >> GO TO 2. NO >> Repair or replace harness or connectors. 2. CHECK AUDIO UNIT VOLTAGE 1. Connect audio unit connector M94. 2. Turn ignition switch ON. 3. Check voltage between audio unit connector M94 and ground. Is the inspection result normal? YES >> Replace Bose speaker amp. Refer to AV-214, "Removal and Installation" NO >> Replace audio unit. Refer to AV-203, "Removal and Installation" . Audio unit Bose speaker amp. Continuity Connector Terminal Connector Terminal M94 1 B43 18 Yes Audio unit Ground Continuity Connector Terminal M94 1 — No Audio unit Ground Voltage (Approx.) (+) (–) Connector Terminal M94 1 — Battery voltage |
