GI-12 < HOW TO USE THIS MANUAL > HOW TO READ WIRING DIAGRAMS • The switch diagram is used in wiring diagrams. Connector Information INFOID:0000000010122897 HOW TO USE CONNECTOR INFORMATION Description JSAIA0017GB Number Item Description 1 Connector number • Alphabetic characters show to which harness the connector is placed. 2 Connector type • This means the connector number. 3 Terminal number • This means the terminal number of a connector. JCAWA0152GB |
