GI-4 < HOW TO USE THIS MANUAL > HOW TO USE THIS MANUAL Standard Contents INFOID:0000000010122889 • A QUICK REFERENCE INDEX, a black tab (e.g. ) is provided on the first page. You can quickly find the first page of each section by matching it to the section's black tab. • THE CONTENTS are listed on the first page of each section. • THE TITLE is indicated on the upper portion of each page and shows the part or system. • THE PAGE NUMBER of each section consists of two or three letters which designate the particular section and a number (e.g. “BR-5”). • THE SMALL ILLUSTRATIONS show the important steps such as inspection, use of special tools, knacks of work and hidden or tricky steps which are not shown in the previous large illustrations. Assembly, inspection and adjustment procedures for the complicated units such as the automatic transaxle or transmission, etc. are presented in a step-by-step format where necessary. Relation between Illustrations and Descriptions INFOID:0000000010122890 The following sample explains the relationship between the part description in an illustration, the part name in the text and the service procedures. Components INFOID:0000000010122891 • THE LARGE ILLUSTRATIONS are exploded views (see the following) and contain tightening torques, lubri- cation points, section number of the PARTS CATALOG (e.g. SEC. 440) and other information necessary to perform repairs. Outer Socket Lock Nut : 59 - 78 N·m (6.0 - 8.0 kg-m, 43 - 58 ft-lb) Drive Shaft Installation Bolt : 44.3 N·m (4.5 kg-m, 33 ft-lb) SAIA0519E |
