SYSTEM (INTELLIGENT KEY SYSTEM)

DLK-27

< SYSTEM DESCRIPTION >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

AUTO DOOR LOCK FUNCTION

After door is unlocked by door request switch operation and if 60 seconds or more passes without performing

the following operation, all doors are automatically locked. However, operation check function does not acti-

vate.

Auto door lock mode can be changed by the “AUTO LOCK SET” in “Work support”. Refer to

BCS-20, "INTEL-

LIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)"

.

LIST OF OPERATION RELATED PARTS

Parts marked with

× are the parts related to operation.

BACK DOOR OPEN FUNCTION
BACK DOOR OPEN FUNCTION : System Description

INFOID:0000000010119726

SYSTEM DIAGRAM

BACK DOOR OPEN OPERATION

This section describes the operation of the back door opener switch. The operation of the back door opener

request switch is the same as the door lock function. Refer to

DLK-35, "System Description"

Operating condition

• Door switch is ON (door is open)
• Door is locked
• Power switch is pressed

Door lock function

In

tel

lig

en

t Ke

y

Re

mo

te

 ke

yl

es

s en

try rec

e

ive

r

Do

or swi

tch

Doo

r re

qu

es

t s

w

itc

h

Do

or l

o

ck ac

tu

at

or

In

si

de

 ke

an

ten

na

O

ut

sid

e ke

y ant

en

na

CAN co

mm

un

ic

at

io

sys

tem

BCM

Hazard warning

lamp

Powe

r swi

tch

Co

mb

in

at

ion

 met

er

Door lock/unlock function

×

×

×

×

×

×

×

×

Hazard reminder function

×

×

×

×

Door lock status indicator operation

×

Selective unlock function

×

×

×

×

×

×

Auto door lock function

×

×

×

×

JMKIA6681GB

DLK-28

< SYSTEM DESCRIPTION >

SYSTEM (INTELLIGENT KEY SYSTEM)

• The back door open function can open the back door by pressing the back door opener switch while carrying

the Intelligent Key and all doors are locked.

• The back door open function enables the back door to be opened by pressing back door opener switch after

BCM transmits UNLOCK signal to each door.

BACK DOOR OPEN

• When the BCM detects that back door opener switch is pressed, it starts the outside key antenna (rear

bumper) and inside key antenna and transmits the request signal to the Intelligent Key. Then, check that the

Intelligent Key is near the back door.

• If the Intelligent Key is within the outside key antenna detection area, it receives the request signal and

transmits the key ID signal to the BCM via remote keyless entry receiver.

• BCM receives the key ID signal and compares it with the registered key ID.

• BCM opens back door and simultaneously unlocks all doors.

NOTE:

In selective unlock mode, only back door opens. All doors do not unlock.

OPERATION CONDITION

If the following conditions are satisfied, the back door can be opened:

OUTSIDE KEY ANTENNA DETECTION AREA

The outside key antenna detection area of back door open function

is in the range of approximately 80 cm (31.50 in) surrounding the

back door opener switch (1). However, this operating range depends

on the ambient conditions.

LIST OF OPERATION RELATED PARTS

Parts marked with

× are the parts related to operation.

REMOTE KEYLESS ENTRY FUNCTION

Back door open function

Operation condition

Back door open operation

• Vehicle speed is less than 5 km/h (3 MPH)
• Panic alarm is not activated
• Intelligent Key is outside of vehicle
• Intelligent Key is within outside key antenna detection area
• Back door is closed

JMKIA6141ZZ

Back door open function

In

te

lli

ge

nt Key

Re

mo

te

ke

yl

es

s e

nt

ry re

ce

iv

er

Ba

ck

 d

oo

r op

en

er

ac

tua

to

r

Do

or l

oc

ac

tua

to

r

Insi

de

 ke

y a

n

ten

n

a

Out

sid

e k

e

y a

n

te

nn

a (rea

r bu

mp

er)

CAN c

o

mm

un

ic

ati

on

 sy

st

em

BCM

Ba

ck

 d

oo

r op

en

er

swit

ch

Co

mb

in

ati

on

 me

te

r

Back door open function

×

×

×

×

×

×

×

×

×

×

SYSTEM (INTELLIGENT KEY SYSTEM)

DLK-29

< SYSTEM DESCRIPTION >

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

REMOTE KEYLESS ENTRY FUNCTION : System Description

INFOID:0000000010119727

SYSTEM DIAGRAM

BASIC OPERATION

The Intelligent Key has the same functions as the remote control entry system. Therefore, it can be used in the

same manner as the remote controller by operating the door lock/unlock button.

OPERATION

Remote keyless entry system controls operation of the following items:

• Door lock/unlock

• Selective Unlock function

• Hazard reminder function

• Auto door lock

OPERATION AREA

To check that the Intelligent Key works normally, use within 1 m (3 ft) range of each doors, however the opera-

ble range may differ according to surroundings.

DOOR LOCK/UNLOCK FUNCTION

• When door lock/unlock button of the Intelligent Key is pressed, lock signal or unlock signal transmitted from

Intelligent Key to BCM via remote keyless entry receiver.

• BCM receives the signal and compares it with the registered key ID to the vehicle.

• When BCM receives the door lock/unlock signal, it operates all door lock actuators and the hazard lamp

(lock: 2 time, unlock: 1 times) and horn chirp signal to IPDM E/R at the same time as a reminder.

• IPDM E/R honks horn (lock: 1 times) as a reminder.

OPERATION CONDITION

If the following condition are satisfied, remote keyless entry operation is performed when the Intelligent Key is

operated:

SELECTIVE UNLOCK FUNCTION

• When an LOCK signal is transmitted from Intelligent Key, all doors are locked.

• When an UNLOCK signal is transmitted from Intelligent Key once, driver side door is unlocked.

• Then, if an UNLOCK signal is transmitted from Intelligent Key again within 60 seconds, all other doors are

unlocked.

How To Change Selective Unlock Operation Mode

Selective unlock operation mode can be changed using CONSULT.

Refer to

BCS-20, "INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)"

.

HAZARD AND HORN REMINDER FUNCTION

JMKIA6676GB

Remote controller operation

Operation condition

Lock / Unlock

Panic alarm is not activated

DLK-30

< SYSTEM DESCRIPTION >

SYSTEM (INTELLIGENT KEY SYSTEM)

When doors are locked or unlocked by Intelligent Key, BCM blinks hazard warning lamps as a reminder and

transmits horn chirp signal to IPDM E/R. IPDM E/R sounds horn as a reminder.

The hazard and horn reminder has a horn chirp mode (C mode) and a non-horn chirp mode (S mode).

Operating Function of Hazard and Horn Reminder

Hazard and horn reminder does not operate if power switch ON position.

How to change hazard and horn reminder mode

 With CONSULT

Refer to

BCS-20, "INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)"

.

 Without CONSULT

When LOCK and UNLOCK signals are sent from the Intelligent Key for more than 2 seconds at the same time,

the hazard and horn reminder mode is changed and hazard warning lamp blinks and horn sounds as per the

following items:

AUTO DOOR LOCK FUNCTION

After door is unlocked by Intelligent Key button operation and if 60 seconds or more passes without performing

the following operation, all doors are locked. However, operation check function does not activate.

How To Change Auto Door Lock Operation Mode

Auto door lock operation mode can be changed using CONSULT.

Refer to

BCS-20, "INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)"

.

LIST OF OPERATION RELATED PARTS

Parts marked with

× are the parts related to operation.

C mode

S mode

Intelligent Key operation

Lock

Unlock

Back door

open

Lock

Unlock

Back door

open

Hazard warning lamp blinks

Twice

Once

Twice

Horn  sound

Once

JMKIA6362GB

Operating condition

• Door switch is ON (door is open)
• Door  is  locked
• Power switch is pressed

Remote keyless entry functions

Int

ell

ig

en

t Ke

y

Doo

r swi

tch

Doo

r lo

ck actu

ato

r

Power swi

tch

In

te

lli

gen

t K

ey warn

in

g b

uzze

r

CAN c

o

m

m

un

ica

tio

n sy

st

em

BCM

Com

bin

at

ion

 m

ete

r

Hazard warning lamp

IPDM

 E/R

Door lock/unlock function by remote control button

×

×

×

×

×

Hazard reminder function

×

×

×

×

×

×

×

×
