Nissan Leaf. Manual - part 147





AV

INSPECTION AND ADJUSTMENT

AV-579

< BASIC INSPECTION >

[TELEMATICS SYSTEM]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ADDITIONAL SERVICE WHEN TCU CONNECTING CENTER CHANGED
ADDITIONAL SERVICE WHEN TCU CONNECTING CENTER CHANGED : Descrip-
tion

INFOID:0000000010122749

When TCU connecting center change must be performed manually, below operation is required.

Operation to change the connecting center

Use CONSULT and enter connecting center of TCU.

ADDITIONAL SERVICE WHEN TCU CONNECTING CENTER CHANGED : Work Pro-
cedure

INFOID:0000000010122750

1.

INFORMATION CENTER CONNECTION SETTINGS

CONSULT work support

1. Wait for 5 seconds or more after turning the power switch ON.

2. Touch “TELEMATICS” on the CONSULT screen.

3. After performing System Call of CONSULT, touch the “Work support” tab.

4. On the work support screen of CONSULT, select “CENTER CONNECTION SETTING” and touch “Start.”

5. On the CENTER CONNECTION SETTING screen, touch “Start.”

>> GO TO 2.

2.

INPUT OF PERSONAL ID AND PASSWORD (USER OPERATION)

1. Enter personal ID and password by vehicle operation.
2. Press “  (Zero emission)”of multifunction switch.

3. Select “CARWINGS” and check radio wave status of TELEMAT-

ICS indicated on the top right.

4. Select “CARWINGS”

→“CARWINGS settings”→“Sign in.”

5. Enter user ID and password to select “Register.”

6. Voice guidance is heard, and the communication with the Infor-

mation Center starts.

7. Test results from the Information Center are shown on the dis-

play.

Check displayed results.

Displays registration completion screen.>>GO TO 3.

Displays “Can't connect to center”>>Check  user  ID  and password. Go back to Step 2 [2.INPUT OF PER-

SONAL ID AND PASSWORD (USER OPERATION)].

3.

CONFIRMATION OF OPERATION

1. Press “  (Zero emission)” of multifunction switch.

2. Select “CARWINGS”

→“All Information Feeds”→Contents of Info from NISSAN.

Check displayed results.

Displays contents of All Information Feeds.>>WORK END

Displays “Can't connect to center”>>Select and check a different item of All Information Feeds, or GO TO 2.

A.

Radio wave state (Service Area)

B.

Radio wave state (Out of Service Area)

JSNIA4475ZZ

AV-580

< DTC/CIRCUIT DIAGNOSIS >

[TELEMATICS SYSTEM]

U1000 CAN COMM CIRCUIT

DTC/CIRCUIT DIAGNOSIS

U1000 CAN COMM CIRCUIT

Description

INFOID:0000000010122751

CAN (Controller Area Network) is a serial communication line for real time applications. It is an on board multi-

plex communication line with high data communication speed and excellent error detection ability. A modern

vehicle is equipped with many ECMs, and each control unit shares information and links with other control

units during operation (not independent). In CAN communication, 2 control units are connected with 2 commu-

nication lines (CAN H-line and CAN L-line) allowing a high rate of information transmission with less wiring.

Each control unit transmits/receives data but selectively reads required data only.

Refer to

LAN-37, "CAN COMMUNICATION SYSTEM : CAN Communication Signal Chart"

 for details of the

communication signal.

DTC Logic

INFOID:0000000010122752

DTC DETECTION LOGIC

Diagnosis Procedure

INFOID:0000000010122753

1.

PERFORM SELF-DIAGNOSIS

1. Turn the power switch ON and hold it for 2 seconds or more.

2. Check the self-diagnosis result of “multi-AV”.
Is CAN communication system displayed?

YES

>> Refer to

LAN-17, "Trouble Diagnosis Procedure"

.

NO

>> Refer to

GI-53, "Intermittent Incident"

.

DTC

Display contents of CON-

SULT

Malfunction detection condition

Probable malfunction location

U1000

CAN COMM CIRC [U1000]

When the AV control unit cannot communicate for 2 sec-
onds or more.

CAN communication system

AV

U1010 CONTROL UNIT (CAN)

AV-581

< DTC/CIRCUIT DIAGNOSIS >

[TELEMATICS SYSTEM]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

U1010 CONTROL UNIT (CAN)

DTC Logic

INFOID:0000000010122754

DTC DETECTION LOGIC

DTC

Display contents of CON-

SULT

Malfunction detection condition

Action to take

U1010

CONTROL UNIT (CAN)
[U1010]

Malfunction is detected during initial diagnosis of the AV
control unit CAN controller.

Replace the AV control unit if
malfunction constantly occurs.
Refer to

AV-593, "Removal

and Installation"

.

AV-582

< DTC/CIRCUIT DIAGNOSIS >

[TELEMATICS SYSTEM]

U1A00 TCU

U1A00 TCU

DTC Logic

INFOID:0000000010122755

Diagnosis Procedure

INFOID:0000000010122756

1.

CHECK ACC POWER CIRCUIT

1. Check the ACC power circuit. Refer to

AV-590, "TCU : Diagnosis Procedure"

.

Is the check result normal?

YES

>> Replace TCU. Refer to

AV-594, "Removal and Installation"

.

NO

>> Repair or replace the harness or connectors.

DTC

Display contents of CON-

SULT

DTC detection condition

Action to take

U1A00

ACC NO CONN
[U1A00]

No input of ACC signal

• Check the ACC power cir-

cuit. Refer to

AV-590, "TCU

: Diagnosis Procedure"

.

• If the ACC circuit is normal,

replace TCU. Refer to

AV-

594, "Removal and Installa-
tion"

.
