SEC-114

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

POWER SWITCH

POWER SWITCH

Removal and Installation

INFOID:0000000010119320

REMOVAL

1. Remove the NATS antenna amp. Refer to

SEC-113, "Removal and Installation"

.

2. Remove the power switch (1).

1. Disengage the power switch fixing pawls.

2. Press the power switch to remove it from instrument lower

panel (LH) (2).

INSTALLATION

Install in the reverse order of removal.

: Pawl

JMKIA8654ZZ

VEHICLE SECURITY HORN

SEC-115

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

VEHICLE SECURITY HORN

Removal and Installation

INFOID:0000000010119321

REMOVAL

1. Remove the front under cover. Refer to

EXT-23, "FRONT UNDER COVER : Removal and Installation"

.

2. Disconnect the harness connectors (A) from the vehicle security

horn (1).

3. Remove the vehicle security horn bolt (B) and the vehicle secu-

rity horn (1).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA3112ZZ

SEC-116

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

HOOD SWITCH

HOOD SWITCH

Removal and Installation

INFOID:0000000010119322

NOTE:

The hood switch is available for Mexico only.

The hood switch is part of the hood lock assembly. For removal and installation refer to

DLK-187, "HOOD

LOCK : Removal and Installation"

.

DONGLE UNIT

SEC-117

< REMOVAL AND INSTALLATION >

[WITH INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

SEC

N

O

P

DONGLE UNIT

Removal and Installation

INFOID:0000000010119323

REMOVAL

1. Remove the glove box lid. Refer to

IP-17, "Removal and Installation"

2. Disconnect the harness connector to the dongle unit.
3. Remove the dongle unit bolt and dongle unit.

INSTALLATION

Installation is in the reverse order of removal.
