ASSEMBLY 1. Assemble 5th synchronizer. I Be careful not to hook front and rear ends of spread 2. Install bearing retainer. 3. Press on input shaft front bearing. 4. Install input gear spacer. 5. Select correct snap ring of input shaft front bearing to minimize Allowable clearance of groove: 0 - 0.1 mm (0 - 0.004 in) Snap rings of input shaft front bearing: Refer to SDS, MT-87. 6. Install 5th gear needle bearing, 5th input gear, 5th synchro- 7. Measure gear end play as a final check — Refer to “Disassem- SMT736A SMT761B Spread spring Shifting insert SMT731 ST22350000 Bearing retainer SMT708B Snap ring SMT779A ST37750000 5th REPAIR FOR COMPONENT PARTS RS5F32A Input Shaft and Gears (Cont’d) MT-23 |
