Nissan Primera P11. Manual - part 508

NCMT0003

NVH

T

roubleshooting

Chart

NCMT0003S01

Use

the

chart

below

to
help

you

find

the

cause

of
the

symptom.

The

numbers

indicate

the

order

of
the

inspec-

tion.

If

necessary

,

repair

or
replace

these

parts.

Reference

page

Refer to MA section (“Checking
M/T Oil”, “CHASSIS AND BODY
MAINTENANCE”).

MT-15, 48

MT-15, 48

MT-15, 48

MT-14, 47

MT-17, 50

MT-17, 50

MT-16, 49

MT-16, 49

MT-16, 49

MT-16, 49

SUSPECTED

P

A

R

T

S

(Possible

cause)

(Oil level is low.)

(Wrong oil)

(Oil level is high.)

GASKET (Damaged)

OIL SEAL (Worn or damaged)

O-RING (Worn or damaged)

CONTROL ROD (Worn)

CHECK PLUG RETURN SPRING AND CHECK BALL (Worn or damaged)

SHIFT FORK (Worn)

GEAR (Worn or damaged)

BEARING (Worn or damaged)

BAULK RING (Worn or damaged)

INSERT SPRING, SHIFTING INSERT (Damaged)

Symptom

Noise

1

2

3

3

Oil

leakage

31222

Hard

to
shift

or
will

not

shift

1

1

2

3

3

Jumps

out

of
gear

1233

NOISE,

V

IBRATION

AND

HARSHNESS

(NVH)

T

ROUBLESHOOTING

NVH

T

roubleshooting

Chart

MT-7

Replacing Oil Seal

NCMT0005

DIFFERENTIAL OIL SEAL

NCMT0005S01

1.

Drain gear oil from transaxle.

2.

Remove drive shafts — Refer to section FA.

3.

Remove differential oil seal.

4.

Install differential oil seal.

I

Apply multi-purpose grease to seal lip of oil seal before
installing.

5.

Install drive shafts — Refer to section FA.

I

Install differential oil seal so that dimension “A” and “B”
are within specifications.

Unit: mm (in)

Item

A

B

F32A

5.9 - 6.1 (0.232 - 0.240)

0.5 (0.020) or less

F70A

0.5 (0.020) or less

STRIKING ROD OIL SEAL

NCMT0005S02

1.

Remove transaxle control rod from yoke.

2.

Remove retaining pin of yoke.

I

Be careful not to damage boot.

SMT563A

ST33290001

SMT564AB

Drift

.

Drift: LH side ST33400001 (F31A)

KV31103000 and ST35325000 (F32A
& F32V) RH side ST30720000 (F31A)
LH and RH side KV38100200 (F70A)

SMT738B

F32A

Transmission
case side

Clutch housing side

Oil seal

SMT869D

Transaxle case side

Clutch housing side

Differential oil seal

Differential oil seal

F70A

SMT565A

KV32101000

ON-VEHICLE SERVICE

Replacing Oil Seal

MT-8

3.

Remove striking rod oil seal.

4.

Install striking rod oil seal.

I

Apply multi-purpose grease to seal lip of oil seal before
installing.

Position Switch Check

NCMT0006

BACK-UP LAMP SWITCH

NCMT0006S01

I

Check continuity

Gear Position

Continuity

Reverse

Yes

Except reverse

No

NEUTRAL POSITION SWITCH

NCMT0006S02

I

Check continuity.

Gear position

Continuity

Neutral

Yes

Except neutral

No

SMT566A

Drift

SMT570A

Drift

SMT715B

Back-up lamp
switch harness
connector

Neutral position
switch connector

F31A and F32A

NMT090

Back-up lamp
switch harness
connector

Neutral position
switch harness
connector

F70A

ON-VEHICLE SERVICE

Replacing Oil Seal (Cont’d)

MT-9

Removal

NCMT0007S01

1.

Remove battery negative terminal.

2.

Remove air duct.

3.

Disconnect clutch control cable from transaxle (GA16 models).

4.

Remove clutch operating cylinder from transaxle (except GA16
models).

5.

Disconnect back-up lamp switch, speedometer sensor, neutral
position switch and ground harness connectors.

6.

Remove starter motor from transaxle.

7.

Remove shift control rod and support rod from transaxle.

8.

Drain gear oil from transaxle.

9.

Remove exhaust front tube.

10. Draw out drive shafts from transaxle — Refer to section FA.

.

SMT653B

Front

SMT654B

.

Starter motor

Front

SMT655B

Shift control rod

Shift support rod

.

F31A and F32A

NMT091

.

Control rod

.

Support rod

.

F70A

SMT656B

Knuckle
spindle
upper nut

Drive shaft

REMOVAL AND INSTALLATION

Removal

MT-10
