Trouble Diagnoses
Symptom
Possible cause
Repair order
Turn signal and hazard warning
lamps do not operate.
1. Hazard switch
1. Check hazard switch.
2. Turn signal switch
2. Check turn signal switch.
3. Harness connector
E104
3. Check harness connector
E104
.
Turn signal lamps do not operate
but hazard warning lamps oper-
ate.
1. Turn signal switch
1. Check turn signal switch.
2. Open in turn signal switch cir-
cuit
2. Check L/G and G/Y wires between time control
unit and turn signal switch for open circuit.
3. Check B wire between turn signal switch and
ground for open circuit.
Hazard warning lamps do not
operate but turn signal lamps
operate.
1. Hazard switch
1. Check hazard switch.
2. Open in hazard switch circuit
2. Check G/R wire between time control unit and
hazard switch for open circuit.
Check B wire between hazard switch unit and
ground for open circuit.
Front turn signal lamp LH or RH
does not operate.
1. Bulb
1. Check bulb.
2. Grounds
2. Check grounds
E11
and
E37
.
Rear turn signal lamp LH or RH
does not operate.
1. Bulb
1. Check bulb.
2. Grounds
2. Check grounds
T3
and
T4
or
B48
and
D110
or
B150
and
B151
.
LH and RH turn indicators do not
operate.
1. Grounds
1. Check grounds
E11
and
E37
.
LH or RH turn indicator does not
operate.
1. Bulb
1. Check bulb in combination meter.
TURN SIGNAL AND HAZARD WARNING LAMPS
EL-123
