DIESEL ENGINE MODELS

YEL130C

BATTERY

Refer to EL-POWER.

IGNITION
SWITCH

BATTERY

STARTER
MOTOR

ST

ON

ACC

OFF

STARTING SYSTEM

Wiring Diagram — START — (Cont’d)

EL-39

Trouble Diagnoses

If any abnormality is found, immediately disconnect battery negative terminal.

Starter does not stop.

왘

Replace magnetic switch.

Engine does not start.

Does engine turn by cranking?

No

왘

Yes

Does engine turn normally?

No (Turns slowly.)

왘

Yes

Check ignition/fuel system.

Check battery as follows:

●

Charging condition

●

Terminal connections

●

Terminal corrosion

NG

왘

OK

Repair starter motor.

쑗

A

Does starter motor turn?

No

왘

Yes

Does gear shaft turn?

No

왘

Yes

Check pinion clutch.

Check reduction gear, armature
and gear shaft.

Check fuse and fusible link.

OK

왘

NG

Replace.

Check battery as follows:

●

Charging condition

●

Terminal connections

●

Terminal corrosion

OK

쑗

A

왘

NG

●

Charge battery.

●

Repair connections and corro-
sion of battery terminals.

Check starting system wiring.

OK

왘

NG

Repair.

Does magnetic switch operation
sound occur?

Yes

왘

No

Replace magnetic switch

Check condition of pinion and
ring gear mesh.

NG

왘

OK

Does starter turn under no load
by connecting wires as follows?

SEL009Z

왘

Yes

Replace magnetic switch.

●

Adjust pinion movement.

●

Check pinion moving mecha-
nism.

●

Check ring gear.

왘

No

Repair starter motor.

왔

왔

왔

왔

왔

왔

왔

왔

왔

왔

왔

왔

STARTING SYSTEM

EL-40

Construction

MEL675EB

Through-bolts

4.9 - 6.4
(0.50 - 0.65,
43.4 - 56.40)

Internal gear

Planetary gear

Pinion shaft

Thrust washer

E-ring

Pinion assembly

Pinion stopper

6.4 - 7.8
(0.65 - 0.80, 56.4 - 69.4)

Gear case assembly

Shift lever set

Dust cover kit

Center bracket (P)

Magnetic switch assembly

7.4 - 9.8
(0.75 - 1.00, 65.1 - 86.8)

Packing

Rear cover assembly

Thrust washer

Brush spring

.

Brush

(-)

.

Brush

(+)

Armature assembly

Yoke assembly

Center bracket (A)

N·m (kg-m, in-lb)

High-temperature grease point

Brush assembly

SEC. 233
S114-806A

YEL420B

Through-bolts

4.9 - 6.4
(0.50 - 0.65,
43.4 - 56.40)

Internal gear

Planetary gear

Pinion shaft

Thrust washer

E-ring

Pinion assembly

Pinion stopper

6.4 - 7.8
(0.65 - 0.80, 56.4 - 69.4)

Gear case assembly

Shift lever set

Dust cover kit

Center bracket (P)

Magnetic switch assembly

7.4 - 9.8
(0.75 - 1.00, 65.1 - 86.8)

Packing

Rear cover assembly

Thrust washer

Brush spring

Brush

(-)

Brush

(+)

Armature assembly

Yoke assembly

Center bracket (A)

: N·m (kg-m, in-lb)

: High-temperature grease point

Brush assembly

SEC. 233
S114-871

STARTING SYSTEM

EL-41

쑗

1

Shift lever

쑗

2

Adjusting plate

쑗

3

Magnetic switch assembly

쑗

4

Internal gear

쑗

5

Planetary gear

쑗

6

Pinion shaft

쑗

7

Rear cover

쑗

8

Brush spring

쑗

9

Brush (−)

쑗

10

Brush (+)

쑗

11

Armature

쑗

12

Yoke

쑗

13

Pinion assembly

쑗

14

Gear case

YEL421B

쑗

4

4.9 - 6.4
(0.50 - 0.65,
43.4 - 56.4)

1.7 - 2.4
(0.17 - 0.24,
14.8 - 20.8)

쑗

1

쑗

2

쑗

3

쑗

6

쑗

5

쑗

7

쑗

8

쑗

9

쑗

10

쑗

11

쑗

12

쑗

13

쑗

14

6.4 - 8.3
(0.65 - 0.85, 56.4 - 73.8)

: N·m (kg-m, in-lb)
: High-temperature

grease point

SEC. 233
S114-800B

STARTING SYSTEM

Construction (Cont’d)
