EM-28 < REMOVAL AND INSTALLATION > [VQ40DE] INTAKE MANIFOLD INTAKE MANIFOLD Exploded View INFOID:0000000009484454 Removal and Installation INFOID:0000000009484455 NOTE: When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spill- ing. REMOVAL 1. Remove intake manifold collector. Refer to EM-25, "Removal and Installation" 2. Remove fuel tube and fuel injector assembly. Refer to EM-45, "Removal and Installation" 3. Loosen nuts and bolts with power tool in reverse order as shown to remove intake manifold. 4. Remove gaskets. CAUTION: Cover engine openings to avoid entry of foreign materials. INSPECTION AFTER REMOVAL Surface Distortion 1. Intake manifold 2. Gasket PBIC2878E PBIC2879E |
