SENSOR ROTOR BRC-233 < UNIT REMOVAL AND INSTALLATION > [TYPE 2] C D E G H I J K L M A B BRC N O P SENSOR ROTOR Removal and Installation INFOID:0000000009482882 FRONT The wheel sensor rotors are built into the wheel hubs and are not removable. If damaged, replace wheel hub and bearing assembly. Refer to FAX-8, "Removal and Installation" REAR Removal NOTE: It is necessary to disassemble the rear axle to replace the sensor rotor. RAX-20, "Removal and Installation" 2. Pull the sensor rotor of off the axle shaft using Tool and a press. Installation 1. Install new sensor rotor on axle shaft using a suitable length steel tube and a press. Make sure sensor rotor is fully seated. CAUTION: Do not reuse the sensor rotor. 2. Install axle shaft assembly. Refer to (M226). CAUTION: Do not reuse the axle oil seal. Tool number : ST30031000 ( — ) WFIA0341E |
