Nissan March K13. Manual - part 434
LAN-24
< SYSTEM DESCRIPTION >
[CAN]
SYSTEM
T: Transmit
R: Receive
Signal name
ECM
ABS
IPDM
-E
TCM
EPS
M&A
BCM
A/C compressor request signal
T
R
Accelerator pedal position signal
T
R
Closed throttle position signal
T
R
Cooling fan speed request signal
T
R
Engine and CVT integrated control signal
T
R
R
T
Engine coolant temperature signal
T
R
Engine speed signal
T
R
R
Engine status signal
T
R
Fuel consumption monitor signal
T
R
Malfunctioning indicator lamp signal
T
R
Power generation command value signal
*1
T
R
ABS warning lamp signal
T
R
Brake warning lamp signal
T
R
Vehicle speed signal (ABS)
T
R
R
R
R
Detention switch signal
T
R
Front wiper stop position signal
T
R
High beam status signal
R
T
Ignition switch ON signal
T
R
R
T
Interlock/PNP switch signal
T
R
R
T
Low beam status signal
R
T
Oil pressure switch signal
T
R
R
T
Push-button ignition switch status signal
T
R
Rear window defogger control signal
*2
R
T
R
T
Sleep-ready signal
T
R
T
R
Starter control relay signal
T
R
R
T
Starter relay status signal
T
R
R
T
Steering lock relay signal
T
R
R
T
OD OFF indicator signal
T
R
Shift position signal
T
R
Vehicle speed signal (TCM)
*3
T
R
EPS operation signal
R
T
EPS warning lamp signal
T
R
Odometer signal
T
R
