SERVICE DATA AND SPECIFICATIONS (SDS)

FAX-23

< SERVICE DATA AND SPECIFICATIONS (SDS)

C

E

F

G

H

I

J

K

L

M

A

B

FAX

N

O

P

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

Wheel Bearing

INFOID:0000000006046121

Drive Shaft

INFOID:0000000006044474

Item

Standard

Axial end play

0.05 mm (0.002 in) or less

Rotating torque

1.9 N·m (0.19 kg-m, 17 in-lb·) or less

Spring balance measurement

13.0 N (1.3 kg, 2.92lb) or less

Item

Standard

Grease quantity

Wheel side

55 – 75 g (1.94 – 2.65 oz)

Transaxle side

85 – 105 g (3.00 – 3.70 oz)

Boots installed length

Wheel side

119.5 mm (4.70 in)

Transaxle side

163.9 mm (6.45 in)

Dimension of dynamic
damper

Right side

246 – 252 mm (9.69 – 9.92 in)

FL-1

ENGINE

C

D

E

F

G

H

I

J

K

L

M

SECTION

FL

A

FL

N

O

P

CONTENTS

FUEL SYSTEM

HR12DE

PRECAUTION ...............................................

2

PRECAUTIONS ...................................................

2

General Precautions  .................................................

2

PREPARATION ............................................

3

PREPARATION ...................................................

3

Special Service Tool  .................................................

3

Commercial Service Tools  ........................................

3

PERIODIC MAINTENANCE ..........................

4

FUEL SYSTEM  ....................................................

4

Inspection ..................................................................

4

Quick Connector  .......................................................

4

REMOVAL AND INSTALLATION  ................

5

FUEL LEVEL SENSOR UNIT, FUEL FILTER
AND FUEL PUMP ASSEMBLY  .........................

5

Exploded View ..........................................................

5

Removal and Installation  ..........................................

5

Inspection .................................................................

8

FUEL TANK  .......................................................

9

Exploded View ..........................................................

9

Removal and Installation  ..........................................

9

Inspection ................................................................

11

SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................

12

SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................

12

Fuel Tank .................................................................

12

FL-2

< PRECAUTION >

[HR12DE]

PRECAUTIONS

PRECAUTION

PRECAUTIONS

General Precautions

INFOID:0000000005988482

WARNING:

When replacing fuel line parts, be sure to observe the following.
• Put a “CAUTION: FLAMMABLE” sign in the workshop.
• Be sure to work in a well ventilated area and furnish workshop with a CO

2

 fire extinguisher.

• Never smoke while servicing fuel system. Keep open flames and sparks away from the work area.

CAUTION:

• Use gasoline required by the regulations for octane number. Refer to

GI-27, "Fuel"

.

• Before removing fuel line parts, perform out the following procedures:
- Put drained fuel in an explosion-proof container and put the lid on securely. Keep the container in

safe area.

- Release fuel pressure from the fuel lines. Refer to

EC-113, "Work Procedure"

.

- Disconnect the battery cable from the negative terminal.
• Always replace O-ring and clamps with new ones.
• Never kink or twist tubes when they are being installed.
• Never tighten hose clamps excessively to avoid damaging hoses.
• After installing tubes, check there is no fuel leakage at connections in the following steps.
- Apply fuel pressure to fuel lines with turning ignition switch “ON” (with engine stopped). Then check

for fuel leakage at connections.

- Start engine and rev it up and check for fuel leakage at connections.
• Use only a genuine NISSAN fuel filler cap as a replacement. If an incorrect fuel filler cap is used, the

“MI” may come on.

• For servicing “EVAPORATIVE EMISSION SYSTEM” parts, refer to

EC-313, "Hydraulic Layout"

.
