MT-10 [RS6F51R] M/T OIL M/T OIL PFP:KLD20 Changing M/T Oil ECS0095N DRAINING 1. Start the engine and let it run to warm up the transaxle. 2. Stop the engine. Remove drain plug and drain oil. 3. Set a gasket on the drain plug and install it to the transaxle. CAUTION: Do not reuse gasket. FILLING 1. Remove filler plug. Fill with new oil until oil level reaches the specified limit near filler plug mounting hole. 2. After refilling oil, check oil level. Assemble gasket to filler plug, then install it to transaxle body. CAUTION: Do not reuse gasket. Checking M/T Oil ECS0095O OIL LEAKAGE AND OIL LEVEL ● Check that oil is not leaking from transaxle or around it. ● Check oil level from filler plug mounting hole as shown in the fig- CAUTION: Never start engine while checking oil level. ● Set a new gasket on the filler plug and install it on the transaxle. CAUTION: Do not reuse gasket. Drain plug: : 30 - 39 N·m (3.1 - 3.9 kg-m, 23 - 28 ft-lb) Oil grade : Genuine Nissan gear oil, SAE viscosity Capacity (reference) : Approx. 2.3 (4 lmp pt) Filler plug: : 30 - 39 N·m (3.1 - 3.9 kg-m, 23 - 28 ft-lb) Filler plug: : 30 - 39 N·m (3.1 - 3.9 kg-m, 23 - 28 ft-lb) SCIA0361E |
