Error item
Possible causes
Example of symptom
Action/symptom
GPS antenna
disconnected
Malfunctioning connection between GPS substrate in AV and
NAVI control unit and GPS antenna.
I
Navigation location detection performance
has deteriorated.
(Location correction using GPS is not per-
formed.)
I
GPS receiving status remains gray.
I
Perform the self-diagnosis.
I
When connection between AV and NAVI control unit and GPS
antenna is judged normal by self-diagnosis, the symptom may
be intermittent, caused by impact or vibration.
Low voltage
of GPS
The power voltage supplied to the GPS circuit board has
decreased.
I
Navigation location detection performance
has deteriorated.
(Location correction using GPS is not per-
formed.)
I
GPS receiving status remains gray.
I
Perform the self-diagnosis.
I
When connection between AV and NAVI control unit and GPS
antenna is judged normal by self-diagnosis, the symptom may
be intermittent, caused by impact or vibration.
DVD-ROM
Malfunction
DVD-ROM
Read error
DVD-ROM
Response
Error
Malfunctioning AV and NAVI control unit
—
Dedicated map DVD-ROM is in the system, but the data cannot
be read.
I
The map of a particular location cannot be
displayed.
I
Specific guidance information cannot be dis-
played.
I
Map display is slow.
I
Guidance information display is slow.
I
System has been affected by vibration.
I
Is map DVD-ROM damaged, warped, or dirty?
–
If damaged or warped, the map DVD-ROM is malfunctioning.
–
If dirty, wipe the DVD-ROM clean with a soft cloth.
I
Perform the self-diagnosis.
I
When AV and NAVI control unit is judged normal by self-
diagnosis, the symptom is judged intermittent, caused by
vibration.
AUTO CLIMATE CONTROL
NLEL0605S07
I
“ATC Automatic Air Conditioner” ATC-41, “Self-diagnosis Func-
tion” for the details.
SKIA1621E
SERVICE
NLEL0605S08
I
To set Service schedule, change Journey distance with joy-
stick. At the same time, the marker of journey distance will be
moved.
SKIA1622E
I
To reset to initial distance, select “Reset” and push “ENTER”.
I
When the indicator of “Service Information Display” is set
green, the color of the journey distance marker will be red. And
automatically Service information screen will be displayed
when journey distance is reached on service schedule.
NAVIGATION SYSTEM
Confirmation/Adjustment Mode (Cont’d)
EL-416
