CHECK SHIFT DOWN (D

TO D

)

Move selector lever from “D” to “2” position while driving in D

(O/D OFF).

Does A/T shift from D

(O/D OFF) to 2

Read gear position.

Yes or No

Yes

>> GO TO 4

>> Go To “18. A/T Does Not Shift: D

→

, When Selec-

tor Lever “D”

→

“2” Position”,

AT-237

. Continue ROAD

TEST. Refer to

CHECK ENGINE BRAKE

Does vehicle decelerate by engine brake?

Yes or No

Yes

>> GO TO 5

>> Go To “15. Engine Speed Does Not Return To Idle (Light

Braking D

→

)”,

AT-235

. Continue ROAD TEST.

Refer to

CHECK SHIFT DOWN

Move selector lever from “2” to “1” position while driving in 2

Does A/T shift from 2

to 1

position?

Read gear position.

Yes or No

Yes

>> GO TO 6

>> Go To “19. A/T Does Not Shift: 2

→

, When Selector

lever “2”

→

“1” Position”,

AT-238

. Continue ROAD

TEST. Refer to

AT-51, "TCM SELF-DIAGNOS-

SAT776BA

SAT791GA

SAT778B

TROUBLE DIAGNOSIS — BASIC INSPECTION

AT-85

[EURO-OBD]

CHECK ENGINE BRAKE

Does vehicle decelerate by engine brake?

Yes or No

Yes

>> 1. Stop vehicle.

2. Perform self-diagnosis.

EURO-OBD: Refer to

TIC PROCEDURE (NO TOOLS)"

>> Go To “20. Vehicle Does Not Decelerate By Engine

Brake”,

AT-239

. Continue ROAD TEST. Refer to

AT-68,

"Road Test"

SAT778B

AT-86

[EURO-OBD]

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

PFP:00000

Symptom Chart

ECS00977

Numbers are arranged in order of inspection.
Perform inspections starting with number one and work up.

Symptom

Condition

Diagnostic Item

Reference Page

EURO-OBD

Engine cannot start in “P” and “N”
positions.

AT-214, "2. Engine Cannot Be
Started In “P” and “N” Position"

ON vehicle

1. Ignition switch and starter

EL-11, “Power Supply
Routing”, SC-13, “Starting
System”

2. Control cable adjustment

AT-412, "Park/Neutral Posi-
tion (PNP) Switch Adjust-
ment"

3. PNP switch adjustment

Engine starts in position other than
“N” and “P” positions.

AT-214, "2. Engine Cannot Be
Started In “P” and “N” Position"

ON vehicle

1. Control cable adjustment

AT-412, "Park/Neutral Posi-
tion (PNP) Switch Adjust-
ment"

2. PNP switch adjustment

Transaxle noise in “P” and “N” posi-
tions.

ON vehicle

1. Fluid level

AT-63, "FLUID LEVEL
CHECK"

2. Line pressure test

AT-67, "Line Pressure Test"

3. Throttle position sensor [Accelerator
pedal position (APP) sensor]

AT-183, "DTC P1705
ACCELERATOR PEDAL
POSITION (APP) SEN-
SOR"

4. Vehicle speed sensor·A/T (Revolution
sensor) and vehicle speed sensor·MTR

AT-125, "DTC P0720 VEHI-
CLE SPEED SENSOR A/T
(REVOLUTION SEN-
SOR)"

AT-203, "DTC VEHICLE
SPEED SENSOR MTR"

5. Engine speed signal

AT-131, "DTC P0725
ENGINE SPEED SIGNAL"

OFF vehicle

6. Oil pump

AT-439, "Oil Pump"

7. Torque converter

AT-421, "Locations of
Adjusting Shims, Needle
Bearings, Thrust Washers
and Snap Rings"

Vehicle moves when changing into
“P” position, or parking gear does
not disengage when shifted out of
“P” position.

AT-214, "3. In “P” Position, Vehicle
Moves Forward Or Backward When
Pushed"

ON vehicle

1. Control cable adjustment

AT-417, "Output Shaft, Idler
Gear, Reduction Pinion
Gear and Bearing
Retainer"

OFF vehicle

2. Parking components

AT-436,

"REPAIR FOR COMPO-
NENT PARTS"

Vehicle runs in “N” position.

AT-216, "4. In “N” Position, Vehicle
Moves"

ON vehicle

1. Control cable adjustment

OFF vehicle

2. Forward clutch

3. Reverse clutch

AT-459, "Reverse Clutch"

4. Overrun clutch

AT-218, "6. Vehicle Does Not Creep
Backward In “R” Position"

TROUBLE DIAGNOSIS — GENERAL DESCRIPTION

AT-87

[EURO-OBD]

Vehicle will not run in “R” position
(but runs in “D”, “2” and “1” posi-
tions). Clutch slips.
Very poor acceleration.

ON vehicle

1. Control cable adjustment

AT-67, "Line Pressure Test"

2. Line pressure test

3. Line pressure solenoid valve

AT-166, "DTC P0745 LINE
PRESSURE SOLENOID
VALVE"

4. Control valve assembly

AT-410, "Control Valve
Assembly and Accumula-
tors"

OFF vehicle

5. Reverse clutch

AT-459, "Reverse Clutch"

6. High clutch

AT-463, "High Clutch"

7. Forward clutch

8. Overrun clutch

AT-474, "Low & Reverse
Brake"

9. Low & reverse brake

Vehicle braked when shifting into
“R” position.

ON vehicle

1. Fluid level

AT-63, "A/T Fluid Check"

2. Control cable adjustment

AT-67, "Line Pressure Test"

3. Line pressure test

4. Line pressure solenoid valve

AT-166, "DTC P0745 LINE
PRESSURE SOLENOID
VALVE"

5. Control valve assembly

AT-410, "Control Valve
Assembly and Accumula-
tors"

OFF vehicle

6. High clutch

AT-463, "High Clutch"

7. Brake band

AT-487, "Band Servo Pis-
ton Assembly"

8. Forward clutch

9. Overrun clutch
