PRECAUTIONS
●
Internal failure of stator roller clutch.
●
Heavy clutch debris due to overheating (blue converter).
●
Steel particles or clutch lining material found in fluid filter or on magnet when no internal parts in unit are
worn or damaged — indicates that lining material came from converter.
The torque converter should not be replaced if:
●
The fluid has an odor, is discolored, and there is no evidence of metal or clutch facing particles.
●
The threads in one or more of the converter bolt holes are damaged.
●
Transaxle failure did not display evidence of damaged or worn internal parts, steel particles or clutch plate
lining material in unit and inside the fluid filter.
●
Vehicle has been exposed to high mileage (only). The exception may be where the torque converter
clutch dampener plate lining has seen excess wear by vehicles operated in heavy and/or constant traffic,
such as taxi, delivery or police use.
EURO-OBD SELF-DIAGNOSIS — EURO-OBD —
●
A/T self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through
the blinking pattern of the O/D OFF indicator lamp or the malfunction indicator (MI). Refer to the table on
AT-42, "SELF-DIAGNOSTIC RESULT TEST MODE"
for the indicator used to display each self-diagnostic
result.
●
The self-diagnostic results indicated by the MI are automatically stored in both the ECM and TCM memo-
ries.
Always perform the procedure
to complete the repair and avoid
unnecessary blinking of the MI.
●
The following self-diagnostic items can be detected using ECM self-diagnostic results mode* only when
the O/D OFF indicator lamp does not indicate any malfunctions.
–
PNP switch
–
A/T 1st, 2nd, 3rd, or 4th gear function
*: For details of EURO-OBD, refer to
AT-37, "ON BOARD DIAGNOSTIC SYSTEM DESCRIPTION"
.
●
Certain systems and components, especially those related to EURO-OBD, may use a new style
slide-locking type harness connector.
For description and how to disconnect, refer to EL-7, “HARNESS CONNECTOR”.
Wiring Diagrams and Trouble Diagnosis
ECS0096G
When you read wiring diagrams, refer to the following:
●
GI-11, “How to Read Wiring Diagrams” in GI section.
●
EL-11, “POWER SUPPLY ROUING” in EL section.
When you perform trouble diagnosis, refer to the following:
●
GI-21, “How to Perform Efficient Diagnosis for an Electrical lncident” in GI section.
●
GI-31, “How to Follow Trouble Diagnoses” in GI section.
