PWC-54 < ECU DIAGNOSIS INFORMATION > BCM (BODY CONTROL MODULE) Terminal Wire color Signal name Signal input/ output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition 1 BR Ignition keyhole illumi- Output OFF Door is locked (SW OFF) Battery voltage Door is unlocked (SW ON) 0V 2 P Combination switch Input ON Lighting, turn, wiper OFF 3 SB Combination switch Input ON Lighting, turn, wiper OFF 4 V Combination switch Input ON Lighting, turn, wiper OFF 5 L Combination switch Input ON Lighting, turn, wiper OFF 6 R Combination switch 9 Y Rear window defogger Input ON Rear window defogger switch 0V Rear window defogger switch 5V 11 G/B Ignition switch (ACC Input ACC or ON Ignition switch ACC or ON Battery voltage 12 LG Front door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 13 L Rear door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 15 W Tire pressure warning Input OFF — 5V 18 BR Remote keyless entry Output OFF — 0V SKIA5291E SKIA5292E SKIA5291E SKIA5292E August 2012 2012 Pathfinder |
