BCM (BODY CONTROL MODULE) DEF-21 < ECU DIAGNOSIS INFORMATION > C D E F G H I J K M A B DEF N O P FR FOG SW Front fog lamp switch OFF Off Front fog lamp switch ON On FR WASHER SW Front washer switch OFF Off Front washer switch ON On FR WIPER LOW Front wiper switch OFF Off Front wiper switch LO On FR WIPER HI Front wiper switch OFF Off Front wiper switch HI On FR WIPER INT Front wiper switch OFF Off Front wiper switch INT On FR WIPER STOP Any position other than front wiper stop position Off Front wiper stop position On HAZARD SW When hazard switch is not pressed Off When hazard switch is pressed On HEAD LAMP SW 1 Headlamp switch OFF Off Headlamp switch 1st On HEAD LAMP SW 2 Headlamp switch OFF Off Headlamp switch 1st On HI BEAM SW High beam switch OFF Off High beam switch HI On ID REGST FL1 ID registration of front left tire incomplete YET ID registration of front left tire complete DONE ID REGST FR1 ID registration of front right tire incomplete YET ID registration of front right tire complete DONE ID REGST RL1 ID registration of rear left tire incomplete YET ID registration of rear left tire complete DONE ID REGST RR1 ID registration of rear right tire incomplete YET ID registration of rear right tire complete DONE IGN ON SW Ignition switch OFF or ACC Off Ignition switch ON On IGN SW CAN Ignition switch OFF or ACC Off Ignition switch ON On INT VOLUME Wiper intermittent dial is in a dial position 1 - 7 1 - 7 I-KEY LOCK 1 LOCK button of Intelligent Key is not pressed Off LOCK button of Intelligent Key is pressed On I-KEY PANIC 1 PANIC button of Intelligent Key is not pressed Off PANIC button of Intelligent Key is pressed On I-KEY PW DWN 1 UNLOCK button of Intelligent Key is not pressed Off UNLOCK button of Intelligent Key is pressed for greater than 3 sec- On I-KEY UNLOCK 1 UNLOCK button of Intelligent Key is not pressed Off UNLOCK button of Intelligent Key is pressed On KEY CYL LK-SW Door key cylinder LOCK position Off Door key cylinder other than LOCK position On Monitor Item Condition Value/Status August 2012 2012 Pathfinder |
