DRIVER SEAT CONTROL UNIT
ADP-113
< ECU DIAGNOSIS INFORMATION >
C
D
E
F
G
H
I
K
L
M
A
B
ADP
N
O
P
*: In conjunction with sliding the seat, the door mirrors are positioned.
CANCEL OF FAIL-SAFE MODE
The mode is cancelled when the A/T selector lever is shifted to P position from any other position.
DTC Index
INFOID:0000000007356224
*1
:
• 0: Current malfunction is present
• 1-39: Displayed if any previous malfunction is present when current condition is normal. The numeral value increases by one at each
IGN ON to OFF cycle from 1 to 39. The counter remains at 39 even if the number of cycles exceeds it. However, the counter is reset
to 1 if any malfunction is detected again, the normal operation is resumed and the ignition switch is turned from OFF to ON.
Priority
Function
Priority
Function
1
Seat sliding, (door mirror LH/RH)*
4
Seat lifter-FR
2
Pedal
5
Seat lifter-RR
3
Seat reclining
CONSULT
display
Timing
*1
Item
Reference page
Current mal-
function
Previous mal-
function
CAN COMM CIRCUIT
[U1000]
0
1-39
CAN communication
SEAT SLIDE
[B2112]
0
1-39
Seat slide motor output
SEAT RECLINING
[B2113]
0
1-39
Seat reclining motor output
SEAT LIFTER FRONT
[B2114]
0
1-39
Seat lifting motor front output
SEAT LIFTER REAR
[B2115]
0
1-39
Seat lifting motor rear output
ADJ PEDAL MOTOR
[B2117]
0
1-39
Pedal adjusting motor output
ADJ PEDAL SENSOR
[B2120]
0
1-39
Pedal adjusting sensor input
DETENT SW
[B2126]
0
1-39
Park position switch condition
UART COMM
[B2128]
0
1-39
UART communication
