C1115 WHEEL SENSOR BRC-49 < DTC/CIRCUIT DIAGNOSIS > [TYPE 1] C D E G H I J K L M A B BRC N O P Is the inspection result normal? YES >> Inspection End. NO >> Go to diagnosis procedure. Refer to Special Repair Requirement INFOID:0000000006689854 1. ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION Always perform neutral position adjustment for the steering angle sensor when replacing the ABS actuator and electric unit (control unit). Refer to BRC-12, "ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL . >> GO TO 2 2. CALIBRATION OF DECEL G SENSOR Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit). BRC-13, "CALIBRATION OF DECEL G SENSOR : Description" . >> END Wheel sensor Vehicle speed (DATA MONITOR) FR LH SENSOR Nearly matches the speedometer dis- ± 10% or less) FR RH SENSOR RR LH SENSOR RR RH SENSOR 2011 Pathfinder |
