SRC-84

< SYMPTOM DIAGNOSIS >

SRS AIR BAG SYSTEM

TION METER
Inspect the harness and connectors between the air bag diagnosis sensor unit and the combination meter.
Do the harness or connectors have any visible damage?

YES

>> Replace harness.

>> GO TO 4

CHECK COMBINATION METER

Disconnect the air bag diagnosis sensor unit harness connectors and turn ignition switch ON.
Does “AIR BAG” warning lamp turn on?

YES

>> Replace the air bag diagnosis sensor unit. Refer to

SR-16, "Removal and Installation"

>> Replace the combination meter. Refer to

MWI-96, "Removal and Installation"

2010 Pathfinder

PASSENGER SEAT BELT WARNING SYSTEM

SRC-85

< SYMPTOM DIAGNOSIS >

SRC

PASSENGER SEAT BELT WARNING SYSTEM

Seat Belt Warning System Does Not Function

INFOID:0000000005258618

SEAT BELT WARNING LIGHT

Turn ignition switch ON.
Does the seat belt warning lamp come ON?

YES

>> GO TO 2

>> • Check 10A fuse [No. 14, located in the fuse block (J/B)].

• Check seat belt buckle switch LH.

• Check harness between combination meter and seat belt buckle switch LH.

• Check combination meter. Refer to

MWI-58, "Fail Safe"

SEAT BELT BUCKLE LH

Fasten the seat belt buckle LH.
Does the seat belt warning lamp go OFF?

YES

>> GO TO 3

>> • Check seat belt buckle switch LH.

• Check harness between combination meter and seat belt buckle switch LH.

OCCUPANT CLASSIFICATION SYSTEM

Have a helper sit in the passenger seat.
Does the seat belt warning lamp go ON?

YES

>> GO TO 4

>> • Check occupant classification system. Refer to

SRC-10, "Occupant Classification System

(OCS)"

• Check harness between occupant classification control unit and air bag diagnosis sensor unit.

SEAT BELT BUCKLE RH

Fasten the seat belt buckle RH.
Does the seat belt warning lamp go OFF?

YES

>> System OK.

>> • Check seat belt buckle switch RH.

• Check harness between seat belt buckle switch RH and air bag diagnosis sensor unit.

• Replace air bag diagnosis sensor unit. Refer to

SR-16, "Removal and Installation"

2010 Pathfinder

SRC-86

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000005484538

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS

system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front

air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SR and SB section of this Service Man-

ual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery, and wait at least 3 minutes before performing any service.

Precaution for SRS "AIR BAG" and "SEAT BELT PRE-TENSIONER" Service

INFOID:0000000005258620

• Do not use electrical test equipment to check SRS circuits unless instructed to in this Service Manual.

• Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 min-

utes.

For approximately 3 minutes after the cables are removed, it is still possible for the air bag and seat belt pre-

tensioner to deploy. Therefore, do not work on any SRS connectors or wires until at least 3 minutes have

passed.

• The air bag diagnosis sensor unit must always be installed with the arrow mark “

⇐

” pointing toward the front

of the vehicle for proper operation. Also check air bag diagnosis sensor unit for cracks, deformities or rust

before installation and replace as required.

• The spiral cable must be aligned with the neutral position since its rotations are limited. Do not attempt to

turn steering wheel or column after removal of steering gear.

• Handle air bag module carefully. Always place driver and front passenger air bag modules with the pad side

facing upward and seat mounted front side air bag module standing with the stud bolt side facing down.

• Conduct self-diagnosis to check entire SRS for proper function after replacing any components.

• After air bag inflates, the front instrument panel assembly should be replaced if damaged.

Occupant Classification System Precaution

INFOID:0000000005258621

Replace occupant classification system control unit and passenger front seat cushion as an assembly.

2010 Pathfinder
