AV U1250 CAMERA CONTROL UNIT AV-367 < COMPONENT DIAGNOSIS > [BOSE AUDIO WITH NAVIGATION] C D E F G H I J K L M B A O P 1. Connect AV control unit connector. 2. Turn ignition switch ON. 3. Check voltage between AV control unit harness connector M48 terminal 87 and ground. Is voltage approximately 5 volts? YES >> Replace camera control unit. Refer to . NO >> Replace AV control unit. Refer to AV-460, "Removal and Installation" . Connector Terminals Voltage (+) (-) M48 87 Ground Approx. 5V ALNIA0543GB 2010 Pathfinder 2010 Pathfinder |
