DVD PLAYER

AV-279

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

DVD PLAYER

Reference Value

INFOID:0000000005259468

PHYSICAL VALUES

AWNIA1780ZZ

Terminal

Description

Condition

Reference value

(Approx.)

–

Signal name

Input/

Output

(B)

(W)

DVD audio signal LH

Output

Ignition

switch

With operation of the DVD
player

(B)

Ground Ground

—

Ignition

switch

—

(BR)

Ground

Illumination control (pulse
width modulated)

—

With lighting switch ON

—

(L)

Ground CAN communication

Input/

Output

Ignition

switch

—

(BR)

Ground

Video monitor power sup-
ply

Output

Ignition

switch

With DVD player operation

12V

(GR)

Ground Switch power

Output

Ignition

switch

With DVD player operation

(W/L)

Ground VTR (+)

Output

Ignition

switch

With DVD player operation

—

(O/L)

Ground VTR (-)

Output

Ignition

switch

With DVD player operation

—

(Y)

Ground Display ground

—

Ignition

switch

With DVD player operation

(V)

—

Data receive

Input

—

SKIB3609E

2010 Pathfinder

AV-280

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

DVD PLAYER

(R)

(G)

DVD audio signal RH

Output

Ignition

switch

With DVD player operation

(Y)

Ground Battery power

Input

—

12V

(SB)

Ground Illumination power

Input

—

With instrument illumination

12V

(P)

Ground CAN communication

Input/

Output

Ignition

switch

—

(G/B)

Ground ACC power

Input

Ignition

switch

ACC or

—

12V

(P)

Ground Ground

Input

Ignition

switch

—

(G)

Ground Video out

Input

Ignition

switch

ACC or

—

(LG)

—

Data transmit

Output

—

Terminal

Description

Condition

Reference value

(Approx.)

–

Signal name

Input/

Output

SKIB3609E

SKIB2251J

2010 Pathfinder

BLUETOOTH CONTROL UNIT

AV-281

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

BLUETOOTH CONTROL UNIT

Reference Value

INFOID:0000000005259469

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA1784ZZ

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

–

Ignition

switch

Operation

(R/Y)

Ground

Battery power

Input

–

Battery voltage

(G/Y)

Ground

ACC power

Input

ACC/ON

–

Battery voltage

(W/G)

Ground

IGN power

Input

ON/

START

–

Battery voltage

(B)

–

Ground

–

(R)

–

Mic-in signal

Input

–

Shield

–

(W)

(B)

Audio out

Output

ACC/ON

Bluetooth control

unit sends audio sig-

nal

(B)

–

Ground

–

(B)

–

Ground

–

(B)

–

Ground

–

(SB)

Ground

Vehicle speed

input signal (8-

pulse)

Input

When vehicle speed

is approx. 40 km/h

(25 mph)

(W)

Ground

Microphone

power

Output

With Bluetooth ON

SKIB3609E

PKIA1935E

2010 Pathfinder

AV-282

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

BLUETOOTH CONTROL UNIT

(B)

–

Bluetooth an-

tenna

–

(B)

–

Bluetooth an-

tenna

–

(L)

–

M-CAN H

–

(P)

–

M-CAN L

–

Terminal

(Wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

–

Ignition

switch

Operation

2010 Pathfinder

AUDIO SYSTEM

AV-283

< SYMPTOM DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

SYMPTOM DIAGNOSIS

AUDIO SYSTEM

Symptom Table

INFOID:0000000005259470

AUDIO SYSTEM

SATELLITE RADIO

DVD PLAYER

Symptom

Possible cause

Reference page

Inoperative

• AV control unit power circuit
• AV control unit

•

AV-193

•

AV-172

Steering wheel audio control switch does not operate

• Steering wheel audio control switch
• AV control unit

•

AV-229

•

AV-172

All speakers do not sound

• AV control unit
• AV control unit power circuit
• BOSE speaker amp. ON signal
• BOSE speaker amp. power/ground circuit
• BOSE speaker amp.

•

•

•

•

•

One or several speakers do not sound

• Front door speaker
• Front tweeter
• Rear door speaker
• Rear tweeter
• Subwoofer

•

•

•

•

•

Symptom

Possible cause

Reference page

CD cannot be inserted.

AV control unit

AV-172

CD cannot be ejected.

The CD cannot be played.

The sound skips, stops suddenly, or is distorted.

Symptom

Possible cause

Reference page

Inoperative

• Satellite radio tuner power or ground circuit
• Satellite radio tuner communication circuit
• Satellite radio tuner

•

AV-198

•

AV-231

•

AV-307

Right or left channel does not sound

• Satellite radio tuner audio signal circuit
• Satellite radio tuner

•

AV-234

•

AV-307

Symptom

Possible cause

Reference page

DVD player inoperative

• Power supply and ground circuits
• DVD player

•

AV-200

•

AV-301

No sound when playing a DVD

• Audio signal circuits
• AV control unit
• DVD player

•

AV-279

•

AV-172

•

AV-301

Video monitor is inoperative/does not display properly

• Power supply and ground circuits
• Video out circuit
• DVD player
• Display monitor

•

•

•

•

2010 Pathfinder

NORMAL OPERATING CONDITION

AV-285

< SYMPTOM DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

NORMAL OPERATING CONDITION

Description

INFOID:0000000005259471

The majority of the audio concerns are the result of outside causes (bad CD, electromagnetic interference,

etc.).

NOISE

The following noise results from variations in field strength, such as fading noise and multi-path noise, or

external noise from trains and other sources. It is not a malfunction.

• Fading noise: This noise occurs because of variations in the field strength in a narrow range due to moun-

tains or buildings blocking the signal.

• Multi-path noise: This noise results from the waves sent directly from the broadcast station arriving at the

antenna at a different time from the waves which reflect off mountains or buildings.

The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning.

Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and opera-

tion of each piece of electrical equipment, and determine the cause.

NOTE:

The source of the noise can be found easily by listening to the noise while removing the fuses of electrical

components, one by one.

Type of Noise and Possible Cause

Occurrence condition

Possible cause

Occurs only when engine is ON.

A continuous growling noise occurs. The speed of
the noise varies with changes in the engine speed.

• Ignition components

The occurrence of the noise is linked with the operation of the fuel pump.

• Fuel pump condenser

Noise only occurs when various
electrical components are oper-
ating.

A cracking or snapping sound occurs with the op-
eration of various switches.

• Relay malfunction, AV control unit malfunc-

tion

The noise occurs when various motors are operat-
ing.

• Motor case ground
• Motor

The noise occurs constantly, not just under certain conditions.

• Rear defogger coil malfunction
• Open circuit in printed heater
• Poor ground of antenna feeder line

A cracking or snapping sound occurs while the vehicle is being driven, especially when
it is vibrating excessively.

• Ground wire of body parts
• Ground due to improper part installation
• Wiring connections or a short circuit

2010 Pathfinder

AV-286

< PRECAUTION >

[BOSE AUDIO WITHOUT NAVIGATION]

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000005259472

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS

system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front

air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SR and SB section of this Service Man-

ual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery, and wait at least 3 minutes before performing any service.

Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

INFOID:0000000005259473

NOTE:

• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-

TEM).

• Remove and install all control units after disconnecting both battery cables with the ignition knob in the

″

LOCK

″

position.

• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.

If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-

anism is adopted on the key cylinder.

For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and

steering wheel rotation will become impossible.

If steering wheel rotation is required when battery power is interrupted, follow the procedure below before

starting the repair operation.

OPERATION PROCEDURE

1. Connect both battery cables.

NOTE:

Supply power using jumper cables if battery is discharged.

2. Use the Intelligent Key or mechanical key to turn the ignition switch to the

″

ACC

″

position. At this time, the

steering lock will be released.

3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be

rotated.

4. Perform the necessary repair operation.
