BODY SIDE TRIM INT-17 < ON-VEHICLE REPAIR > C D E F G H I K L M A B INT N O P Removal and Installation INFOID:0000000003937560 LOWER DASH SIDE FINISHER Removal 1. Remove the push pin from lower dash side finisher. 2. Remove the front kick plate from center pillar lower finisher. 3. Remove the lower dash side finisher and the front kick plate together. 4. Remove the lower dash side finisher from the front kick plate. Installation Installation is in the reverse order of removal. CENTER PILLAR LOWER FINISHER Removal 1. Remove the seat belt anchor. Refer to SB-12, "Removal and Installation" • On RH side, disconnect seat belt tension sensor. 2. Remove the front and rear kick plates. 3. Remove the center pillar lower finisher. Installation Installation is in the reverse order of removal. CENTER PILLAR UPPER FINISHER Removal 1. Remove the front and rear door welts. 2. Remove the seat belt shoulder anchor and D-ring. Refer to SB-12, "Removal and Installation" . 3. Remove the front and rear kick plates. 4. Remove the center pillar lower finisher. 5. Remove the center pillar assist grip. 6. Remove the center pillar upper finisher. Installation Installation is in the reverse order of removal. FRONT PILLAR UPPER FINISHER Removal 1. Remove the front pillar assist grip. 2. Remove the front pillar upper finisher bolt. 3. Remove the front pillar upper finisher. Installation Installation is in the reverse order of removal. FRONT PILLAR LOWER FINISHER Removal 1. Remove the lower dash side finisher. Refer to INT-23, "Removal and Installation"INT-23, "Removal and . 2. Remove the front pillar lower finisher. Installation Installation is in the reverse order of removal. KICK PLATES Removal Release clips and remove the front and/or rear kick plates. Installation 2009 Pathfinder |
