DLN-170 < DISASSEMBLY AND ASSEMBLY > [TRANSFER: ATX14B] TRANSFER ASSEMBLY • Check each control valve spring for damage or distortion. Also check its free length, outer diameter and wire diameter. If any dam- DLN-187, "Inspection and Adjustment" CAUTION: Replace control valve body together with clutch return spring Clutch • Check the drive plate facings and driven plate for damage, cracks or other abnormality. If any abnormalities are found, replace with a • Check the thickness of the drive plate facings and driven plate. DLN-187, "Inspection and Adjustment" CAUTION: • Measure facing thickness at 3 points to take an average. Return Spring • Check the stamped mark shown. Then, check that the free lengths, (include thickness of plate) are within specifications. If any abnor- DLN-187, "Inspection and Adjust- . ASSEMBLY Center Case 1. Apply ATF to the new O-ring, and install it on the oil filter stud. CAUTION: Do not reuse O-rings. 2. Install the oil filter stud to the oil filter. SMT948C SMT949C SDIA2176E SDIA3180E 2009 Pathfinder |
