TROUBLE DIAGNOSIS
AT-79
D
E
F
G
H
I
J
K
L
M
A
B
AT
2006 Pathfinder
41
Slips/Will
Not
Engage
While accelerating in
5th, engine races or
slippage occurs.
ON vehicle
1. Fluid level and state
2. Line pressure test
3. Accelerator pedal position sensor
4. CAN communication line
5. ATF pressure switch 1 and front brake solenoid valve
6. Control valve with TCM
OFF vehicle
7. Torque converter
8. Oil pump assembly
9. Front brake (brake band)
10. Input clutch
11. Gear system
12. High and low reverse clutch
42
Slips at lock-up.
ON vehicle
1. Fluid level and state
2. Line pressure test
3. Engine speed signal
4. Turbine revolution sensor
5. Torque converter clutch solenoid valve
6. CAN communication line
7. Control valve with TCM
OFF vehicle
8. Torque converter
9. Oil pump assembly
43
No creep at all.
Refer to
"Vehicle Does Not
Creep Backward In
“R” Position"
"Vehicle Does Not
Creep Forward In “D”
Position"
ON vehicle
1. Fluid level and state
2. Line pressure test
3. Accelerator pedal position sensor
4. ATF pressure switch 5 and direct clutch solenoid valve
5. PNP switch
6. CAN communication line
7. Control cable adjustment
8. Control valve with TCM
OFF vehicle
9. Torque converter
10. Oil pump assembly
11. 1st one-way clutch
12. Gear system
13. Reverse brake
14. Direct clutch
15. Forward one- way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
16. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
No.
Items
Symptom
Condition
Diagnostic Item
Reference
page
