WHEEL HUB FAX-5 C E F G H I J K L M A B FAX
2005 Pathfinder WHEEL HUB PFP:43202 On-Vehicle Inspection and Service EDS001I6 Make sure the mounting conditions (looseness, backlash) of each component and component status (wear, WHEEL BEARING INSPECTION ● Move wheel hub in the axial direction by hand. Make sure there ● Rotate wheel hub and make sure there is no unusual noise or Removal and Installation EDS001I7 REMOVAL 1. Remove wheel and tire using power tool. 2. Without disassembling the hydraulic lines, remove caliper torque member bolts using power tool. Then BR-25, "Removal and Installation of Brake Caliper and . CAUTION: Do not press brake pedal while brake caliper is removed. Axial end play limit : 0.05 mm (0.002 in) or less SMA571A 1. Disc rotor 2. Wheel hub and bearing assembly 3. Wheel stud 4. Splash guard 5. Steering knuckle 6. Wheel sensor bracket WDIA0228E |
