FRONT TIMING CHAIN CASE EM-49 C D E F G H I J K L M A EM
2005 Pathfinder INSTALLATION 1. Hammer dowel pins (right and left) into front timing chain case 2. Install new front oil seal on the front timing chain case. ● Apply new engine oil to both oil seal lip and dust seal lip. ● Install it so that each seal lip is oriented as shown. ● Press-fit oil seal until it becomes flush with front timing chain ● Make sure the garter spring is in position and seal lip is not 3. Install water pump cover and chain tensioner cover to front timing chain case, if removed. ● Apply a continuous bead of liquid gasket using Tool to front Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-45, "Recommended Chemical Products and Sealants" . PBIC2615E SEM715A PBIC2911E Tool number : WS39930000 ( — ) PBIC2912E |
