ROCKER COVER EM-41 C D E F G H I J K L M A EM
2005 Pathfinder 7. Loosen bolts with power tool in reverse order as shown. 8. Remove rocker cover gaskets from rocker covers. 9. Use scraper to remove all traces of liquid gasket from cylinder head and camshaft bracket (No. 1). CAUTION: Do not scratch or damage the mating surface when cleaning off old liquid gasket. INSTALLATION (LEFT BANK) 1. Apply liquid gasket using Tool to joint part among rocker cover, Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-45, "Recommended Chemical Products and Sealants" . NOTE: a. Refer to the figure “a” to apply liquid gasket to joint part of cam- b. Refer to the figure “b” to apply liquid gasket to the figure “a” 2. Install new rocker cover gasket to rocker cover. 3. Install rocker cover. ● Check if rocker cover gasket is not dropped from installation groove of rocker cover. PBIC2906E Tool number : WS39930000 ( — ) PBIC2474E |
