MWI BCM (BODY CONTROL MODULE) MWI-75 < ECU DIAGNOSIS > C D E F G H I J K L M B A O P 34 (B) Ground Trunk room antenna Output Ignition switch When Intelligent Key is in When Intelligent Key is 35 (W) Ground Trunk room antenna Output Ignition switch When Intelligent Key is in When Intelligent Key is 38 (L/O) Ground Rear bumper anten- Output When the trunk lid When Intelligent Key is in When Intelligent Key is Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB |
