EXL-358
< ON-VEHICLE REPAIR >
[HALOGEN TYPE]
LICENSE PLATE LAMP
LICENSE PLATE LAMP
Exploded View
INFOID:0000000003894381
Removal and Installation
INFOID:0000000003894382
CAUTION:
Disconnect the battery negative terminal or remove the fuse.
REMOVAL
1.
Remove the trunk lid finisher inner. Refer to
2.
Remove the trunk lid finisher outer. Refer to
3.
Remove the license plate lamp while pushing a resin clip.
4.
Disconnect the license plate lamp connector.
INSTALLATION
Install in the reverse order of removal.
Replacement
INFOID:0000000003894383
CAUTION:
• Disconnect the battery negative terminal or remove the fuse.
• Never touch the glass of bulb directly by hand. Keep grease and other oily matters away from it.
Never touch bulb by hand while it is lit or right after being turned off.
• Never leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
LICENSE PLATE LAMP BULB
1.
Remove the trunk lid finisher inner. Refer to
1.
License plate lamp
A.
Resin clip
JPLIA1100ZZ
