Nissan Teana J32. Manual - part 281
CHG
SERVICE DATA AND SPECIFICATIONS (SDS)
CHG-25
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Alternator
INFOID:0000000003860542
Applied model
VQ25DE, VQ35DE
Type
A003TJ1791
MITSUBISHI make
Nominal rating
[V - A]
12 - 130
Ground polarity
Negative
Minimum revolution under no-load (When 13.5 V is ap-
plied)
[rpm]
Less than 1,300
Hot output current (When 13.5 V is applied)
[A/rpm]
More than 61/1,500
More than 109/2,500
More than 129/5,000
Regulated output voltage
[V]
14.1 - 14.7
Minimum length of brush
[mm (in)]
More than 5.00 (0.197)
Brush spring pressure
[N (g, oz)]
4.1 - 5.3 (418 - 541, 14.7 - 19.1)
Slip ring minimum outer diameter
[mm (in)]
More than 22.1 (0.870)
Rotor (Field coil) resistance
[
Ω
]
1.8 - 2.2
