AV
CAMERA CONTROL UNIT
AV-619
< ECU DIAGNOSIS >
[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
M
B
A
O
P
26
(O)
Ground
Vehicle speed signal
(8-pulse)
Input
Ignition
switch
ON
When vehicle speed is ap-
prox. 40 km/h (25 MPH).
NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).
30
(V)
Ground
ACC power supply
Input
Ignition
switch
ACC
—
Battery voltage
31
(B/R)
Ground
Ground
—
Ignition
switch
ON
—
0 V
32
(Y)
Ground
Battery power supply
Input
Ignition
switch
OFF
—
Battery voltage
Terminal
(Wire color)
Description
Condition
Reference value
(Approx.)
+
–
Signal name
Input/
Output
JSNIA0012GB
