WCS COMBINATION METER WCS-27 < ECU DIAGNOSIS > C D E F G H I J K L M B A O P OIL W/L Ignition switch Oil pressure warning lamp ON On Oil pressure warning lamp OFF Off MIL Ignition switch Malfunction indicator lamp ON On Malfunction indicator lamp OFF Off CRUISE IND Ignition switch Cruise indicator lamp ON On Cruise indicator lamp OFF Off SPORT IND Ignition switch SPORT indicator lamp ON On SPORT indicator lamp OFF Off 4WD W/L Ignition switch NOTE: Off 4WD LOCK IND Ignition switch NOTE: Off FUEL W/L Ignition switch Low-fuel warning lamp ON On Low-fuel warning lamp OFF Off WASHER W/L Ignition switch NOTE: Off KEY G/Y W/L Ignition switch KEY warning lamp (green/yellow) ON On KEY warning lamp (green/yellow) OFF Off LCD Ignition switch Engine start information display B&P I Ignition switch Engine start information display B&P N Ignition switch Key ID warning display ID NG Ignition switch Steering lock information display ROTAT Ignition switch P position warning display SFT P Ignition switch Intelligent Key insert information display INSRT Ignition switch Intelligent Key low battery warning display BATT Ignition switch Take away warning display NO KY Ignition switch Key warning display OUTKY Ignition switch ACC warning display LK WN SHIFT IND Ignition switch Shift position indicator P display P Shift position indicator R display R Shift position indicator N display N Shift position indicator D display D Shift position indicator L display L O/D OFF SW Ignition switch Sport mode switch pressed On Other than the above Off Monitor Item Condition Value/Status |
