Nissan Teana J32. Manual - part 1170





TM-204

< FUNCTION DIAGNOSIS >

[CVT: RE0F10A]

DIAGNOSIS SYSTEM (TCM)

DIAGNOSIS SYSTEM (TCM)

CONSULT-III Function (TRANSMISSION)

INFOID:0000000003806374

FUNCTION

CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.

WORK SUPPORT MODE

Display Item List

Engine Brake Adjustment

CAUTION:

Mode of “+1”“0”“

1”“

2”“OFF” can be selected by touching “UP” or “DOWN” on CONSULT-III screen.

However, do not select mode other than “0” and “OFF”. Selecting “+1” or “

1” or “

2” is selected, that

may cause irregular driveability.

Check CVT Fluid Deterioration Date

CAUTION:

Touch “CLEAR” after changing CVT fluid, and then erase “CVTF DETERIORATION DATE”.

SELF DIAGNOSTIC RESULT MODE

Display Items List

Refer to

TM-284, "DTC Index"

.

DATA MONITOR MODE

Display Items List

Diagnostic test mode

Function

Work Support

This mode enables a technician to adjust some devices faster and more accurately.

Self Diagnostic Results

Retrieve DTC from ECU and display diagnostic items.

Data Monitor

Monitor the input/output signal of the control unit in real time.

CAN Diagnosis

This mode displays a network diagnosis result about CAN by a diagram.

CAN Diagnosis Support Mon-
itor

It monitors the status of CAN communication.

ECU Identification

Display the ECU identification number (part number etc.) of the selected system.

Special Function

Other results or histories, etc. that are recorded in ECU are displayed.

Item name

Description

ENGINE BRAKE ADJ.

The engine brake level setting can be canceled.

CONFORM CVTF DETERIORTN

The CVT fluid deterioration level can be checked.

“ENGINE BRAKE LEVEL”

0:

Initial set value (Engine brake level control is activated)

OFF:

Engine brake level control is deactivated.

“CVTF DETERIORATION DATE”

More than 210000:

It is necessary to change CVT fluid.

Less than 210000:

It is not necessary to change CVT fluid.

DIAGNOSIS SYSTEM (TCM)

TM-205

< FUNCTION DIAGNOSIS >

[CVT: RE0F10A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

 X: Standard, —: Not applicable,

: Option

Monitored item (Unit)

Monitor item selection

Remarks

 ECU IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

VSP SENSOR (km/h)

X

Output speed sensor (secondary speed sensor)

ESTM VSP SIG (km/h)

X

PRI SPEED SEN (rpm)

X

ENG SPEED SIG (rpm)

X

SEC HYDR SEN (V)

X

PRI HYDR SEN (V)

X

ATF TEMP SEN (V)

X

CVT fluid temperature sensor

VIGN SEN (V)

 X

VEHICLE SPEED (km/h)

X

Vehicle speed recognized by the TCM.

PRI SPEED (rpm)

X

Primary pulley speed

SEC SPEED (rpm)

Secondary pulley speed

ENG SPEED (rpm)

X

SLIP REV (rpm)

X

Difference between engine speed and primary
pulley speed.

GEAR RATIO

X

G SPEED (G)

ACC PEDAL OPEN (0.0/8)

X

X

Degree of opening for accelerator recognized by
the TCM.
For fail-safe operation, the specific value used for
control is displayed.

TRQ RTO

SEC PRESS (MPa)

X

PRI PRESS (MPa)

X

Not mounted but displayed.

ATFTEMP COUNT

X

Means CVT fluid temperature. Actual oil temper-
ature

°

C (

°

F) numeric value is converted. Refer to

TM-301

DSR REV (rpm)

DGEAR RATIO

DSTM STEP (step)

STM STEP (step)

X

LU PRS (MPa)

LINE PRS (MPa)

TGT SEC PRESS (MPa)

ISOLT1 (A)

X

Torque converter clutch solenoid valve output
current

ISOLT2 (A)

X

Pressure control solenoid valve A (line pressure
solenoid valve) output current

ISOLT3 (A)

X

Pressure control solenoid valve B (secondary
pressure solenoid valve) output current

TM-206

< FUNCTION DIAGNOSIS >

[CVT: RE0F10A]

DIAGNOSIS SYSTEM (TCM)

SOLMON1 (A)

X

X

Torque converter clutch solenoid valve monitor
current

SOLMON2 (A)

X

X

Pressure control solenoid valve A (line pressure
solenoid valve) monitor current

SOLMON3 (A)

X

X

Pressure control solenoid valve B (secondary
pressure solenoid valve) monitor current

P POSITION SW (On/Off)

X

R POSITION SW (On/Off)

X

N POSITION SW (On/Off)

X

D POSITION SW (On/Off)

X

L POSITION SW (On/Off)

X

BRAKE SW (On/Off)

X

X

Stop lamp switch (Signal input via CAN communi-
cations)

FULL SW (On/Off)

X

X

Signal input via CAN communications

IDLE SW (On/Off)

X

X

SPORT MODE SW (On/Off)

X

X

STRDWNSW (On/Off)

X

Not mounted but displayed.

STRUPSW (On/Off)

X

DOWNLVR (On/Off)

X

UPLVR (On/Off)

X

NONMMODE (On/Off)

X

MMODE (On/Off)

X

INDLRNG (On/Off)

“L” position indicator output

INDDRNG (On/Off)

“D” position indicator output

INDNRNG (On/Off)

“N” position indicator output

INDRRNG (On/Off)

“R” position indicator output

INDPRNG (On/Off)

“P” position indicator output

CVT LAMP (On/Off)

SPORT MODE IND (On/Off)

MMODE IND (On/Off)

Not mounted but displayed.

SMCOIL D (On/Off)

Step motor coil “D” energizing status

SMCOIL C (On/Off)

Step motor coil “C” energizing status

SMCOIL B (On/Off)

Step motor coil “B” energizing status

SMCOIL A (On/Off)

Step motor coil “A” energizing status

LUSEL SOL OUT (On/Off)

LUSEL SOL MON (On/Off)

VDC ON (On/Off)

X

Monitored item (Unit)

Monitor item selection

Remarks

 ECU IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU

DIAGNOSIS SYSTEM (TCM)

TM-207

< FUNCTION DIAGNOSIS >

[CVT: RE0F10A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

Diagnostic Tool Function

INFOID:0000000003806375

 OBD SELF-DIAGNOSTIC PROCEDURE

Refer to

EC-122, "Diagnosis Tool Function"

.

TCS ON (On/Off)

X

ABS ON (On/Off)

X

ACC ON (On/Off)

X

Not mounted but displayed.

RANGE

X

Indicates position is recognized by TCM. Indi-
cates a specific value required for control when
fail-safe function is activated.

M GEAR POS

X

Not mounted but displayed.

Monitored item (Unit)

Monitor item selection

Remarks

 ECU IN-

PUT SIG-

NALS

MAIN SIG-

NALS

SELEC-

TION

FROM
MENU
