Nissan Teana J32. Manual - part 1145





TM-104

< COMPONENT DIAGNOSIS >

[CVT: RE0F09B]

SHIFT LOCK SYSTEM

JCDWM0253GB

SHIFT LOCK SYSTEM

TM-105

< COMPONENT DIAGNOSIS >

[CVT: RE0F09B]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

Component Function Check

INFOID:0000000003862438

1.

 CHECK CVT SHIFT LOCK OPERATION

1.

Turn ignition switch ON.

2.

Shift the selector lever to the “P” position.

3.

Attempt to shift the selector lever to any other position with the brake pedal released.

Can the selector lever be shifted to any other position?

JCDWM0254GB

TM-106

< COMPONENT DIAGNOSIS >

[CVT: RE0F09B]

SHIFT LOCK SYSTEM

YES

>> Go to

TM-106, "Diagnosis Procedure"

.

NO

>> GO TO 2.

2.

 CHECK CVT SHIFT LOCK OPERATION

Attempt to shift the selector lever to any other position with the brake pedal depressed.

Can the selector lever be shifted to any other position?

YES

>> INSPECTION END

NO

>> Go to

TM-106, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000003862439

1.

 CHECK POWER SOURCE

1.

Turn ignition switch ON.

2.

Check voltage between stop lamp switch vehicle side harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 2.

NO

>>

Check the following.

• Harness for short or open between fuse block J/B connector terminal 4F and stop lamp switch

harness connector terminal 3

• 10 A fuse [No. 3, located in the fuse block J/B]
• Ignition switch

2.

CHECK STOP LAMP SWITCH

Check stop lamp switch. Refer to

TM-107, "Component Inspection (Stop Lamp Switch)"

.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Replace stop lamp switch. Refer to

BR-17, "Exploded View"

.

3.

CHECK HARNESS BETWEEN STOP LAMP SWITCH AND CONTROL DEVICE (PART 1)

1.

Turn ignition switch OFF.

2.

Disconnect stop lamp switch vehicle side harness connector and control device vehicle side harness con-
nector.

3.

Check continuity between stop lamp switch vehicle side harness connector terminal and control device
vehicle side harness connector terminal.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace damaged parts

4.

CHECK HARNESS BETWEEN STOP LAMP SWITCH AND CONTROL DEVICE (PART 2)

Check continuity between stop lamp switch vehicle side harness connector terminal and ground.

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Repair or replace damaged parts

Stop lamp switch vehicle side harness connector

Ground

Voltage (Approx.)

Connector

Terminal

E115

3

Battery Voltage

Stop lamp switch vehicle side harness connector

Control device vehicle side harness connector

Continuity

Connector

Terminal

Connector

Terminal

E115

4

M57

6

Existed

Stop lamp switch vehicle side harness connector

Ground

Continuity

Connector

Terminal

E115

4

Not existed

SHIFT LOCK SYSTEM

TM-107

< COMPONENT DIAGNOSIS >

[CVT: RE0F09B]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

5.

CHECK GROUND CIRCUIT

Check continuity between control device vehicle side harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 6.

NO

>> Repair or replace damaged parts

6.

CHECK CONTROL DEVICE

1.

Shift selector lever to “P” position.

2.

Check continuity between control device connector.

Is the inspection result normal?

YES

>> INSPECTION END

NO

>> Replace shift lock unit. Refer to

TM-155, "Exploded View"

.

Component Inspection (Stop Lamp Switch)

INFOID:0000000003862440

1.

CHECK STOP LAMP SWITCH

Check continuity between stop lamp switch connector terminals 3 and 4.

Is the inspection result normal?

YES

>> INSPECTION END

NO

>> Replace stop lamp switch. Refer to

BR-17, "Exploded View"

.

Control device vehicle side harness connector

Ground

Continuity

Connector

Terminal

M57

7

Existed

Control device connector

Continuity

Connector

Terminal

M57

6

7

Existed

Stop lamp switch connector

Condition

Continuity

Connector

Terminal

E115

3

4

Depressed brake pedal

Existed

Released brake pedal

Not existed
