Nissan Teana J32. Manual - part 113

AV

DISPLAY UNIT

AV-307

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

NOTE:
The name MULTIFUNCTION SWITCH indicates the integration of PRESET SWITCH and MULTIFUNCTION
SWITCH virtually.

JCNWM0934GB

AV-308

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

BOSE AMP.

BOSE AMP.

Reference Value

INFOID:0000000003793619

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA1094ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(LG)

2

(V)

Sound signal front squawk-
er LH

Output

Ignition

switch

ON

Audio output

4

(P)

3

(L)

Sound signal front squawk-
er RH

Output

Ignition

switch

ON

Audio output

5

(Y)

6

(BR)

Sound signal woofer RH

Output

Ignition

switch

ON

Audio output

7

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

10

(SB)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

11

(GR)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

12

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE AMP.

AV-309

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

13

(R)

8

(BR)

Sound signal woofer LH

Output

Ignition

switch

ON

Audio output

14

(L)

9

(O)

Sound signal rear speaker
RH

Output

Ignition

switch

ON

Audio output

18

(W)

19

(B)

Sound signal front speaker
LH

Output

Ignition

switch

ON

Audio output

20

(V)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

12.0 V

24

(B)

23

(W)

Stereo sound signal front
LH

Input

Ignition

switch

ON

Audio output

26

(W/R)

25

(B/R)

Stereo sound signal front
RH

Input

Ignition

switch

ON

Audio output

28

(G)

15

(R)

Sound signal rear speaker
LH

Output

Ignition

switch

ON

Audio output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-310

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

BOSE AMP.

29

(V)

30

(P)

Sound signal center speak-
er

Output

Ignition

switch

ON

Audio output

31

(BR)

32

(Y)

Sound signal front speaker
RH

Output

Ignition

switch

ON

Audio output

33

(W/L)

34

(GR/V)

Surround sound signal rear
RH

Input

Ignition

switch

ON

When DVD is playing.

*

35

(W/L)

36

(W/R)

Surround sound signal rear
LH

Input

Ignition

switch

ON

When DVD is playing.

*

52

(B)

51

(W)

Surround sound signal front
LH

Input

Ignition

switch

ON

When DVD is playing.

*

54

(Y)

53

(BR)

Surround sound signal front
RH

Input

Ignition

switch

ON

When DVD is playing.

*

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E
