INSPECTION AND ADJUSTMENT

ADP-9

< BASIC INSPECTION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

MEMORY STORING : Special Repair Requirement

INFOID:0000000003759065

Memory Storage Procedure

Two positions for the driver seat can be stored for memory operation by the following procedure.

1.

STEP 1

Shift selector lever to the P position.

>> GO TO 2.

2.

STEP 2

Turn ignition switch ON.

>> GO TO 3.

3.

STEP 3

Adjust driver seat position manually.

>> GO TO 4.

4.

STEP 4

1.

Push set switch.
NOTE:
• Memory indicator for which driver seat position is already retained in memory is illuminated for 5 sec-

onds.

• Memory indicator for which driver seat position is not retained in memory is illuminated for 0.5 seconds.

2.

Push the memory switch (1 or 2) for at least 1 second within 5 seconds after pushing the set switch.
NOTE:
• When entering driver seat positions into blank memory, memory indicator turns ON for 5 seconds.
• When changing driver seat positions, memory indicator turns OFF for 0.5 seconds, then turns ON for 5

seconds.

NOTE:
If memory is stored in the same memory switch, the previous memory will be deleted.

Do you need to link Intelligent Keys?

YES

>> GO TO 5.

NO

>> END

5.

STEP 6

Push the Intelligent Key unlock button within 5 seconds after pushing memory switch (while the memory indi-
cator is ON).

>> GO TO 6.

6.

STEP 7

Confirm the operation of each part with memory operation and Intelligent Key interlock operation.

>> END

SYSTEM SETTING

SYSTEM SETTING : Description

INFOID:0000000003759066

The settings of the automatic driving positioner system can be changed, using CONSULT-III, the display unit
in the center of the instrument panel and the set switch. Always check the settings before and after discon-
necting the battery terminal or replacing driver seat control unit.

Setting Change

ADP-10

< BASIC INSPECTION >

INSPECTION AND ADJUSTMENT

×

: Applicable

SYSTEM SETTING : Special Repair Requirement

INFOID:0000000003759067

1.

 CHOOSE METHOD

There are three ways of setting methods.

Which method do you choose?

With display>>GO TO 2.
With set switch>>GO TO 4.
With CONSULT-III>>GO TO 6.

2.

 WITH DISPLAY - STEP 1

Turn ignition switch ON.

>> GO TO 3.

3.

 WITH DISPLAY - STEP 2

1.

Push “SETTING” button.

2.

Select “Comfort & Conv.”.

3.

Select “Slide Driver

′

s Seat Back ON Exit” on display, then push

-

Slide Driver's Seat Back On Exit: Entry/exit assist (seat)

>> END

4.

 WITH SET SWITCH - STEP 1

Turn ignition switch OFF.

>> GO TO 5.

5.

 WITH SET SWITCH - STEP 2

Push setting button and hold for more than 10 seconds, then confirm blinking of the memory switch indicator.
• Entry/exit assist (seat) are ON: Memory switch indicator blinks two times.
• Entry/exit assist (seat) are OFF: Memory switch indicator blinks once.

>> END

6.

 WITH CONSULT-III - STEP 1

Select “Work support”.

>> GO TO 7.

7.

 WITH CONSULT-III - STEP 2

1.

Select “EXIT SEAT SLIDE SETTING”, or “SEAT SLIDE VOLUME SET” then touch display to change
between ON and OFF.

-

EXIT SEAT SLIDE SETTING: Entry/exit assist (seat)

2.

Then touch “OK”.

Item

Content

CON-

SULT

–III

Display

Set

switch

Factory

setting

Amount of seat sliding for
entry/exit assist

The amount of seat sliding for entry/exit assist can
be selected from 3 items.
[40mm/80mm/150mm]

x

—

—

40mm

Entry/exit assist
(seat)

Entry/exit assist (seat) can be selected:
ON (operated) – OFF (not operated)

x

x

x

ON

Reset custom settings

All settings can be set to default (factory setting).

—

x

—

—

INSPECTION AND ADJUSTMENT

ADP-11

< BASIC INSPECTION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

>> END

ADP-12

< FUNCTION DIAGNOSIS >

AUTOMATIC DRIVE POSITIONER SYSTEM

FUNCTION DIAGNOSIS

AUTOMATIC DRIVE POSITIONER SYSTEM

AUTOMATIC DRIVE POSITIONER SYSTEM

AUTOMATIC DRIVE POSITIONER SYSTEM : System Diagram

INFOID:0000000003759068

AUTOMATIC DRIVE POSITIONER SYSTEM : System Description

INFOID:0000000003759069

OUTLINE

The system automatically moves the driver seat position by the driver seat control unit.

SLEEP MODE

JMJIA1812GB

Function Description

Manual function

The driving position (seat) can be adjusted by using the power seat switch

Memory function

The seat can be adjusted to the stored driving position by pressing seat memory
switch (1 or 2)

Entry/Exit assist function

Exit

On exit, the seat moves backward

Entry

On entry, the seat returns from the exiting position to the previous driving position

Intelligent Key interlock function

Perform memory operation, exiting operation and entry operation by Intelligent Key
unlock operation or driver side door request switch unlock operation
