GW-16

< REMOVAL AND INSTALLATION >

SIDE WINDOW GLASS

1.

Remove the luggage side upper finisher. Refer to

INT-20, "Removal and Installation"

.

2.

Apply protective tape around the side window to protect the painted surface from damage.

3.

Remove the side window glass using piano wire.

WARNING:

Always wear safety glasses and heavy gloves to prevent injury.

CAUTION:

• Be careful not to scratch the glass when removing.
• Never set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions provided

with it.

• Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by

passenger room air pressure when all door windows are closed.

• The molding must be installed securely so that it is in position and leaves no clearance.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive is completely

cured (approximately 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let

them in contact with the skin and eyes.

• Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.

Move immediately to an area with fresh air if affected by vapor inhalation.

• Driving the vehicle before the urethane adhesive is completely cured may affect the performance of

the side window in case of an accident.

CAUTION:

• Never use an adhesive which is past its usable term. Shelf life of this product is limited to six months

after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the
box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Never leave primers or adhesive cartridge unattended with their caps open or off.
• The vehicle should not be driven for at least 24 hours or until the urethane adhesive is completely

cured. Curing time varies depending on temperature and humidity. The curing time will increase
under lower temperature and lower humidity.

Inspection

INFOID:0000000005513259

Repairing Water Leakage for side window glass

Leakage can be repaired without removing glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the side window glass area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.

BACK DOOR WINDOW GLASS

GW-17

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

BACK DOOR WINDOW GLASS

Exploded View

INFOID:0000000005513260

Removal and Installation

INFOID:0000000005513261

REMOVAL

1.

Remove the back door finisher inner. Refer to

INT-38, "Removal and Installation"

.

2.

Remove the connectors and grounds for the back door window defogger.

3.

Remove the rear wiper arm and motor. Refer to

WW-138, "Removal and Installation"

.

1.

Back door outer

2.

Back door inner

3.

Back door window glass

4.

Dam rubber

5.

Adhesive

6.

Primer

7.

Fastener

Unit: mm (in)

Refer to

GI-4, "Components"

 for symbols in the figure.

JMKIA3567GB

GW-18

< REMOVAL AND INSTALLATION >

BACK DOOR WINDOW GLASS

4.

Remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B) after removing
molding using pliers.

• NOTE:

Mark the body and the glass with matching marks if the back door window glass is reused.

WARNING:

Always wear safety glasses and heavy gloves to prevent injury.

CAUTION:

• Never use a cutting knife or power cutting tool when the back door window glass is reused.
• Be careful not to scratch the glass when removing.
• Never set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

• The dam rubber should be installed in position.
• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions provided

with it.

• Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by

passenger compartment air pressure when all door windows are closed.

• Inform the customer that the vehicle should remain stationary until the urethane adhesive is completely

cured (approximately 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never

let them in contact with the skin and eyes.

• Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.

Move immediately to an area with fresh air if affected by vapor inhalation.

• Driving the vehicle before the urethane adhesive is completely cured may affect the performance

of the rear window in case of an accident.

CAUTION:

• Perform adjustment of rear wiper arm stop location. Refer to

WW-138, "Adjustment"

.

• Never use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date
printed on the box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Never leave primers or adhesive cartridge unattended with their caps open or off.
• The vehicle should not be driven for at least 24 hours or until the urethane adhesive is completely

cured. Curing time varies depending on temperature and humidity. The curing time increases
under lower temperature and lower humidity.

• If the substrate of the glass joining surface on the back door panel side is exposed to the air,

exchange the back door assembly without recoating.

• Never apply paint on the back door panel surface which is in contact with the glass when replacing

the back door assembly.

Inspection

INFOID:0000000005513262

REPAIRING WATER LEAKAGE FOR BACK DOOR WINDOW GLASS

Leakage can be repaired without removing the glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the back door window glass area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.

PIIB5779E

FRONT DOOR GLASS

GW-19

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

FRONT DOOR GLASS

Exploded View

INFOID:0000000005513263

Removal and Installation

INFOID:0000000005513264

REMOVAL

1.

Remove the front door finisher. Refer to

INT-12, "FRONT DOOR FINISHER : Removal and Installation"

.

2.

Remove both seals (1) as shown in the figure.

3.

Reconnect the power window main switch.

1.    Front door glass run

2.

Front door glass

3.

Regulator assembly

4.

Module base

5.

Power window motor

6.

Front door inside seal

7.

Front door lower sash

8.

Front door panel

: Vehicle front

JMKIA3604ZZ

JMKIA1279ZZ
