LICENSE PLATE LAMP CIRCUIT
EXL-59
< DTC/CIRCUIT DIAGNOSIS >
[XENON TYPE]
C
D
E
F
G
H
I
J
K
M
A
B
EXL
N
O
P
LICENSE PLATE LAMP CIRCUIT
Component Function Check
INFOID:0000000005515066
1.
CHECK LICENSE PLATE LAMP OPERATION
IPDM E/R AUTO ACTIVE TEST
1.
Activate IPDM E/R auto active test. Refer to
PCS-10, "Diagnosis Description"
.
2.
Check that the license plate lamp is turned ON.
CONSULT-III ACTIVE TEST
1.
Select “EXTERNAL LAMPS” of IPDM E/R active test item.
2.
With operating the lighting switch, check that the license plate lamp is turned ON.
Is the license plate lamp turned ON?
YES
>> License plate lamp circuit is normal.
NO
>> Refer to
.
Diagnosis Procedure
INFOID:0000000005515067
1.
CHECK LICENSE PLATE LAMP BULB
Check the applicable lamp bulb.
Is the bulb normal?
YES
>> GO TO 2.
NO
>> Replace the bulb.
2.
CHECK LICENSE PLATE LAMP OPEN CIRCUIT
1.
Turn the ignition switch OFF.
2.
Disconnect IPDM E/R connector and the license plate lamp connector.
3.
Check continuity between the IPDM E/R harness connector and the license plate lamp harness connec-
tor.
Does continuity exist?
YES
>> GO TO 3.
NO
>> Repair the harnesses or connectors.
3.
CHECK LICENSE PLATE LAMP GROUND OPEN CIRCUIT
Check continuity between the license plate lamp harness connector and the ground.
Does continuity exist?
YES
>> Replace the license plate lamp.
NO
>> Repair the harnesses or connectors.
TAIL
: License plate lamp ON
Off
: License plate lamp OFF
IPDM E/R
License plate lamp
Continuity
Connector
Terminal
Connector
Terminal
RH
E10
7
D163
1
Existed
LH
D162
1
License plate lamp
Ground
Continuity
Connector
Terminal
RH
D163
2
Existed
LH
D162
2
