TILT MOTOR

TILT MOTOR

Description

INFOID:0000000005518198

Tilt motor operates with the power received from automatic drive positioner control unit.

Component Function Check

INFOID:0000000005518199

1.

CHECK TILT MOTOR FUNCTION

Check tilt operation with tilt & telescopic switch.

Is the inspection results normal?

YES

>> Tilt motor is OK.

NO

>> Refer to

SE-44, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000005518200

1.

CHECK TILT MOTOR INPUT SIGNAL

1.

Turn ignition switch OFF.

2.

Disconnect tilt motor connector.

3.

Check voltage between tilt motor harness connector and ground.

Is the inspection result normal?

YES

>> Replace tilt motor.

NO

>> GO TO 2.

2.

CHECK TILT MOTOR CIRCUIT

1.

Disconnect automatic drive positioner control unit connector.

2.

Check continuity between tilt motor harness connector and automatic drive positioner control unit harness
connector.

3.

Check continuity between tilt motor harness connector and ground.

Is the inspection result normal?

YES

>> Replace automatic drive positioner control unit. Refer to

SE-140, "Removal and Installation"

.

NO

>> Repair or replace harness.

(+)

(–)

Condition

Voltage (V)

(Approx.)

Tilt motor

Connector

Terminal

M116

1

Ground

Tilt & telescopic switch is downward position

Battery voltage

Other than above

0

2

Tilt & telescopic switch is upward position

Battery voltage

Other than above

0

 Tilt motor

Automatic drive positioner control

Continuity

 Connector

Terminal

Connector

Terminal

M116

1

M104

28

Existed

2

29

 Tilt motor

Ground

Continuity

 Connector

Terminal

M116

1

Not existed

2

TELESCOPIC MOTOR

SE-45

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

TELESCOPIC MOTOR

Description

INFOID:0000000005518201

Telescopic motor operates with the power received from automatic drive positioner control unit.

Component Function Check

INFOID:0000000005518202

1.

CHECK TELESCOPIC MOTOR FUNCTION

Check telescopic operation with tilt & telescopic switch.

Is the inspection results normal?

YES

>> Telescopic motor is OK.

NO

>> Refer to

SE-45, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000005518203

1.

CHECK TELESCOPIC MOTOR INPUT SIGNAL

1.

Turn ignition switch OFF.

2.

Disconnect telescopic motor connector.

3.

Check voltage between telescopic motor harness connector and ground.

Is the inspection result normal?

YES

>> Replace telescopic motor.

NO

>> GO TO 2.

2.

CHECK TELESCOPIC MOTOR CIRCUIT

1.

Disconnect automatic drive positioner control unit connector.

2.

Check continuity between telescopic motor harness connector and automatic drive positioner control unit
harness connector.

3.

Check continuity between telescopic motor harness connector harness connector and ground.

Is the inspection result normal?

YES

>> Replace automatic drive positioner control unit. Refer to

SE-140, "Removal and Installation"

.

NO

>> Repair or replace harness.

(+)

(–)

Condition

Voltage (V)

(Approx.)

Telescopic motor

Connector

Terminal

M117

1

Ground

Tilt & telescopic switch is backward position

Battery voltage

Other than above

0

2

Tilt & telescopic switch is forward position

Battery voltage

Other than above

0

 Telescopic motor

Automatic drive positioner control

Continuity

 Connector

Terminal

Connector

Terminal

M117

1

M104

26

Existed

2

29

 Telescopic motor

Ground

Continuity

 Connector

Terminal

M117

1

Not existed

2

SE-46

< DTC/CIRCUIT DIAGNOSIS >

POWER SEAT

POWER SEAT

Wiring Diagram - POWER SEAT (FOR DRIVER SIDE) -
