Nissan Murano Z51. Manual - part 115

AV

FRONT DISPLAY UNIT

AV-239

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

JCNWM3209GB

AV-240

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

FRONT DISPLAY UNIT

JCNWM3210GB

AV

BOSE AMP.

AV-241

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BOSE AMP.

Reference Values

INFOID:0000000005528586

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA1223ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(LG)

2

(V)

Sound signal front squawk-
er LH

Output

Ignition

switch

ON

Sound output.

4

(P)

3

(L)

Sound signal front squawk-
er RH

Output

Ignition

switch

ON

Sound output.

5

(Y)

6

(BR)

Sound signal rear speaker
RH

Output

Ignition

switch

ON

Sound output.

7

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

10

(SB)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

11

(GR)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

12

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

SKIB3609E

SKIB3609E

SKIB3609E

AV-242

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

BOSE AMP.

13

(GR)

8

(BR)

Sound signal rear speaker
LH

Output

Ignition

switch

ON

Sound output.

14

(L)

9

(O)

Sound signal rear door
speaker RH

Output

Ignition

switch

ON

Sound output.

16

(B/R)

17

(W/R)

Sound signal woofer

Output

Ignition

switch

ON

Sound output.

18

(W)

19

(B)

Sound signal front door
speaker LH

Output

Ignition

switch

ON

Sound output.

20

(SB)

Ground

Amp. ON signal

Input

Ignition

switch

ACC

—

12.0 V

21

—

Shield

—

—

—

—

22

(W)

Ground

Woofer Amp. ON signal

Output

Ignition

switch

ACC

—

12.0 V

24

(GR/V)

23

(W/L)

Sound signal rear LH

Input

Ignition

switch

ON

Sound output.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E
