Operate the parking brake pedal with a force of 196 N (20 kg, 44 lb). Check that the pedal stroke is within
the specified number of notches. (Check it by listening to the clicks of the ratchet.)

When brake warning lamp turns ON, check that the pedal stroke is within the specified number of
notches. (Check it by listening to the clicks of the ratchet.)

Inspect Components

• Check each component for installation condition such as looseness.
• Check the device assembly for bend, damage and cracks. Replace if necessary.
• Check the cables for wear, damage and cracks. Replace if necessary.
• Check the parking brake switch, and replace it if necessary. Refer to

BRC-78, "Component Inspection"

ADJUSTMENT

Fix the disc rotor using wheel nuts.

Remove fuse block lid. Refer to

IP-12, "Exploded View"

Release the parking brake pedal (1) by turning the adjusting nut
(2) with a deep socket wrench and loosening the cable.

Remove the adjusting hole plug from the disc rotor. Turn the
adjuster (1) in the direction (A) as shown in the figure using a
suitable tool until the disc rotor is locked.

Turn back the adjuster 5 or 6 notches from the locked position.

Rotate the disc rotor to check that there is no drag. Install the
adjusting hole plug.

Adjust the cable with the following procedure.

Operate the parking brake pedal with a force of 490 N (50 kg,
110 lb) for 10 strokes or more.

Adjust the parking brake pedal stroke by turning the adjusting
nut with a deep socket wrench.

CAUTION:

Never reuse the adjusting nut if the nut is removed.

Operate the parking brake pedal with a force of 196 N (20 kg, 44 lb). Check that the pedal stroke is within
the specified number of notches. (Check it by listening to the clicks of the ratchet.)

Standard

Number of notches

: Refer to

PB-11, "Parking Brake Control"

Standard

Number of notches

: Refer to

PB-11, "Parking Brake Control"

JPFIB0044ZZ

JPFIB0002ZZ
