FRONT DISPLAY UNIT

Reference Values

INFOID:0000000005528583

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0006ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

2

(Y)

Ground

Inverter VCC

Input

Ignition

switch

ACC

—

9.0  V

3

(O)

Ground

Signal VCC

Input

Ignition

switch

ACC

—

9.0  V

4

(P)

Ground

Composite image GND

—

Ignition

switch

ON

—

0  V

5

—

Shield

—

—

—

—

6

(L)

Ground

RGB signal (G: green)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

7

—

Shield

—

—

—

—

8

(G)

Ground

Horizontal synchronizing
(HP) signal

Output

Ignition

switch

ON

—

SKIB2236J

SKIB3601E

AV-200

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

FRONT DISPLAY UNIT

9

(W)

Ground

RGB area (YS) signal

Input

Ignition

switch

ON

When RGB image is dis-
played

5.0 V

When AUX image is dis-
played

11

(R)

Ground

Communication signal
(CONT

→

DISP)

Input

Ignition

switch

ON

When adjusting display
brightness.

13

(BR)

Ground

Inverter GND

—

Ignition

switch

ON

—

0  V

14

(LG)

Ground

Signal GND

—

Ignition

switch

ON

—

0  V

15

(L)

4

(P)

Composite image signal

Input

Ignition

switch

ON

When AUX image is dis-
played

17

(G)

Ground

RGB signal (R: red)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

18

(Y)

Ground

RGB signal (B: blue)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

PKIB4948J

PKIB5039J

SKIB2251J

SKIB2238J

SKIB2237J

AV

FRONT DISPLAY UNIT

AV-201

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Wiring Diagram - BOSE AUDIO WITHOUT NAVIGATION WITHOUT DVD ENTER-
TAINMENT SYSTEM -

INFOID:0000000005528584

NOTE:

19

(B)

Ground

RGB synchronizing signal

Input

Ignition

switch

ON

—

20

(R)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

On

—

21

—

Shield

—

—

—

—

22

(G)

Ground

Communication signal
(DISP

→

CONT)

Output

Ignition

switch

ON

When adjusting display
brightness.

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3603E

SKIB3598E

PKIB5039J

AV-202

< ECU DIAGNOSIS INFORMATION >

[BOSE AUDIO WITHOUT NAVIGATION]

FRONT DISPLAY UNIT
